TOC Analyzer
- Models
- TOC-A1500; TOC-A1700
- Detection Range
- 0.001-1.5mg/L
- Method
- Off-line
- Detection Limit
- 1ppb
- Max Tolerance
- ±5%
Scitek is one of the world's leading suppliers of total organic carbon analytical instruments and analyzers.
Added to your inquiry list. It travels with your next quote request.
2 models
Product Description
TOC Analyzer specification across the range. Figures are the manufacturer’s published values.
| Model | TOC-A1500 | TOC-A1700 |
|---|---|---|
| Detection Range | 0.001-1.5mg/L | |
| Method | Off-line | On-line and Off-line |
| Detection Limit | 1ppb | |
| Max Tolerance | ±5% | |
| Analysis Time | 3 min | |
| Response Time | Within 10 min | |
| Sample Temperature | 1-95°C | |
| Environment Temperature | 10-40°C with temperature change ±5℃/d | |
| Sample Flow Speed | 1 ml/min | |
| Relative Humidity | 0.985 | |
| Repeatability Tolerance | ≤3% | |
| Drifting | ±5% | |
| Power Supply | AC 220V, 50/60Hz; 110V, 50/60Hz | |
| Power | 100W | |
| Size(W×D×H)(mm) | 440x220x300 | 440x220x405 |
| Shipping Size (W×D×H)(mm) | 640x490x440 | 650x500x450 |
| N.W./G.W. (kg) | 11/18 | 13/20 |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Total organic carbon analyzer is equipped with conductivity detector quantitative TOC concentration
- The TOC A1700 supports online and offline monitoring in real-time.
- It is the first choice to measure and monitor pure water, microelectronic water, water for injection, etc.
- Automatic sample injection design to ensure the safety of the operator and sample pollution-free
- A UV lamp is used for UV oxidation without adding acid, gas or catalyst.
- 7-inch touch screen, easy to operate
- Auto sampler is optional according to different experiment requirements.
- 8 GB of bulk storage
Applications
Where it is used
- Wastewater treatment plants test incoming and outgoing water
- Water purification plant monitoring of river water and treated water
- Monitoring of treated tap water, river water and rainwater
- Continuous monitoring of plant water, e.g. recycled water, cooling water, boiler water, etc.
