Home/Products/Scitek Global/Thermostatic Water Bath
Heating, cooling & storage
Thermostatic Water Bath
- Models
- WB-1L1HV; WB-1L2HIII; WB-1L3HI; WB-2L4HII; WB-2L6HII; WB-2L8HI
- Temperature Control Range(℃)
- RT+5~99
- Constant Temperature Fluctuation(℃)
- ±0.5
- Tracking Alarm(℃)
- ±2
- Volume(L)
- 4
The 1-8 hole thermostatic water bath is a lab constant temperature equipment, providing heat source for varieties of devices that need heating.
Added to your inquiry list. It travels with your next quote request.
6 models
Product Description
Thermostatic Water Bath specification across the range. Figures are the manufacturer’s published values.
| Model | WB-1L1HV | WB-1L2HIII | WB-1L3HI | WB-2L4HII | WB-2L6HII | WB-2L8HI |
|---|---|---|---|---|---|---|
| Temperature Control Range(℃) | RT+5~99 | |||||
| Constant Temperature Fluctuation(℃) | ±0.5 | |||||
| Tracking Alarm(℃) | ±2 | |||||
| Volume(L) | 4 | 7 | 2.1×3 | 15 | 21 | 27 |
| Power Supply | AC220V, 50/60Hz | |||||
| Power(W) | 350 | 500 | 350×3 | 1000 | 1500 | 2000 |
| Chamber Size (W×D×H)(mm) | 165×160×150 | 310×160×150 | (140×150×100)×3 | 310×310×150 | 460×310×150 | 610×310×150 |
| Sizes (W×D×H)(mm) | 350×230×340 | 520×230×240 | 520×350×280 | 490×380×220 | 650×390×220 | 800×380×220 |
| Shipping Size (W×D×H)(mm) | 610×50×520 | 610×510×520 | 670×570×520 | 670×570×520 | 890×620×540 | 890×620×540 |
| N.W./G.W. (kg) | 5/8 | 7.5/11 | 17/24 | 9.5/14 | 12.8/18 | 13.5/19 |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Advanced electronic temperature control devices.
- Temperature adopts intelligent fuzzy PID control.
- The measured and set values of temperature can be selected with a minimum resolution of 0.1 ℃ or 1 ℃.
- It has the function of switching between Fahrenheit and Celsius degrees.
- The timing function can be selected (none, constant temperature timing, running timing), the timing direction can be selected as positive or countdown, and the timing unit can be selected (minutes, hours). After the timing is completed, a buzzer will sound to prompt (the prompt time can be set).
- With temperature self-turning function.
- Temperature sensor open circuit, short circuit sound and light (buzzer) alarm prompt, and the controller automatically disconnects the heating output.
- The heating tube adopts a U-type stainless steel tube, which is uniformly heated, corrosion-resistant, and with less heat loss.
Next step
Tell us the capacity and the duty.
We will confirm the right model, the price and the lead time.
