Particle Size Analyzer
- Models
- PSA-2308A
- Principle
- Laser diffraction principle
- Analysis
- Mie and Fraunhofer scattering
- Detector Arrangement
- Log-spaced array, test angle from 0.015 degree to 145 degree
- Measuring Range
- Wet: 0.01μm-2000 μm; Dry: 0.1μm-2000μm
With a microfine accuracy of 0.1um, the particle size analyzer's optical path is always in optimal condition, eliminating the hassle and difficulty of manually aligning the optical path whil…
Added to your inquiry list. It travels with your next quote request.
1 models
Product Description
Particle Size Analyzer specification across the range. Figures are the manufacturer’s published values.
| Model | PSA-2308A | |
|---|---|---|
| Principle | Laser diffraction principle | |
| Analysis | Mie and Fraunhofer scattering | |
| Detector Arrangement | Log-spaced array, test angle from 0.015 degree to 145 degree | |
| Measuring Range | Wet: 0.01μm-2000 μm; Dry: 0.1μm-2000μm | |
| Silicon Photodetectors | Wet:127 pcs; Dry:100 pcs | |
| Accuracy Error | Wet<1% Dry<1% (CRM D50) | |
| Repeatability Error | Wet<1% Dry<1% (CRM D50) | |
| Light Source | High performance semiconductor red laser (λ=639nm ) P＞3.0MW Auxiliary green solid semiconductor laser (λ= 405 nm) P＞2.0MW (available) | |
| Optical Path | Converging light Fourier transform optical path | |
| Effective Focal Length | 500mm | |
| Laser Safety | Class 1 | |
| Wet Dispersion | Ultrasonic | Frequency: 40KHz Power: 60W Time: ≥1S |
| Stir | Revolutions Speed: 0-3000RPM (Adjustable) | |
| Circulate | Rated Flow: 30L/min Rated Power: 70W | |
| Water Level Sensor (UK) | Prevent water overflow and effectively protect the instrument | |
| Sample Tank | Volume: 1000mL | |
| Micro- Sample Cuvette | Volume: 10mL ( Available) | |
| Dry Dispersion | Dry-turbulence dispersion patent technology, normal shock wave shear technique | |
| Feeding Speed | Adjustable (Variable speed knob) | |
| Operation Mode | Full automatic / manual control, freely choose | |
| Dispersion Medium | Compressed Air, pressure: 0 to 6 bar | |
| Optical Bench Alignment System | Full automatic, precision is up to 0.2um | |
| Full Test Speed Per Time | Wet: ＜2 min Dry : <1 min Inverval time per test result: 500ms | |
| External Size(L×W×H)(mm) | 1040×440×540 | |
| Shipping Size (W×D×H)(mm) | 1220x640x700 | |
| N.W. / G.W. (kg) | 70/99 | |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Particle size analyzer adopt laser diffraction theory (Mie and Fraunhofer diffraction), measure size is from 0.01μm to 2000μm (dry 0.1μm-2000μm), Which offer reliable and repeatable particle size analysis for a diverse range of applications.
- It use dual-beam & multiple spectral detection systems and side light scatter test technology to significantly improve precision and performance of test.
- Intelligent full automatic operation system and manual operation mode, freely choose.
- Full built-in sample dispersion system.
- Instrument particle size analysis software.
- It is suitable for particle size and surface potential measurement of a variety of different nanoemulsions, suspension colloids, etc. It can be widely used in fine chemical industry nanomaterials, R&D and production quality control of surfactants, oligomers, etc.
- The zeta potential analyzer is also a product development and quality control testing instrument for inks, pharmaceutical preparations and other industries.
- Ultra-high-speed data acquisition.
