Microbe Culture System
- Models
- Specification; Design description; Volume (L); Inner diameter (mm); Height (mm); Theoretical gas consu mption (L; tank)
- Anaerobic
- Microaerobic
- SKJ06P
- 6 90mm plastic plates
- SKJ08P
- 8 90mm plastic plates
- SKJ12P
- 12 90mm plastic plates/ 1 250ml triangular flask
The multifunctional microbe culture system offers precise control for microbial cultivation, featuring adjustable temperature, humidity, and aeration.
Added to your inquiry list. It travels with your next quote request.
7 models
Product Description
Microbe Culture System specification across the range. Figures are the manufacturer’s published values.
| Model | Specification | Design description | Volume (L) | Inner diameter (mm) | Height (mm) | Theoretical gas consu mption (L/tank) | |
|---|---|---|---|---|---|---|---|
| Anaerobic | Microaerobic | ||||||
| SKJ06P | 6 90mm plastic plates | Stackable side interface | 1.5 | 120 | 136 | 3 | 1 |
| SKJ08P | 8 90mm plastic plates | Stackable side interface | 1.8 | 120 | 176 | 3.5 | 1.5 |
| SKJ12P | 12 90mm plastic plates/ 1 250ml triangular flask | Stackable side interface | 2.5 | 120 | 268 | 5.5 | 2 |
| SKJ24P | 3 stacks of 24 90mm plastic plates/6 150mm plates/18 96-well plates/12 2-orifice plates for Campylobacter culture | Stackable side interface | 5 | 214 | 170 | 10 | 3 |
| SKJ32P | 4 stacks of 32 90mm plastic plates /7 150mm plastic plates/18 96- orifice plates | Stackable side interface | 6 | 234 | 170 | 12 | 4 |
| SKJ60P | 5 stacks of 60 90mm plastic plates /4 250ml flasks/22 96-orifice plates | Stackable side interface | 10 | 250 | 227 | 19 | 6 |
| SKJ24P | 3 stacks of 24 90mm plastic plates /7 150mm plastic plates/16 96- orifice plates/10 2-orifice plates for Campylobacter culture | Top interface | 5 | 214 | 203 | 9 | 3 |
| SKJ48 | 4 stacks of 48 90mm plastic plates /4 250ml flasks/22 96-orifice plates | Top interface | 9 | 250 | 260 | 17.5 | 5.5 |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Convenient operation With a 7-inch touch screen, the interface can display the preparation mode and quality control level of multiple channels at the same time, with multiple shortcut programs and custom programs available.
- High preparation efficiency Anaerobic environment preparation time Maximum speed of standard procedure ≤100s, maximum speed of fast procedure ≤60s, Microaerobic environment preparation time, Maximum speed of standard program ≤50s, maximum speed of fast program ≤20s.
- Generation accuracy The generation precision is ±0.1%, which is not affected by altitude, atmospheric pressure, weather, tank size, culture quantity, culture vessel type and other changes.
- Gas source ratio It supports the customization of gas source ratio, and the program can automatically calculate and generate the ambient gas concentration according to the set gas source ratio.
- Data management With data viewing function and USB data export interface, optional printer can realize data printing function.
- Permission management With multi-level authority management function, the administrator can assign authority to different users, and each user has an independent account and password
- Quality control It has a power-on self-test program and five quality control programs. There are 6 quality control levels, and the quality control program can be adjusted according to the experimental requirements and the aging degree of the culture tank.
- Injection needle mode Fully automatic program quickly generates anaerobic environment in small sealed containers such as test tubes and penicillin bottles
