Melting Point Apparatus
- Models
- MPA-70I; MPA-80; MPA-90I
- Capillary Size
- Outer φ1.4mm, inner φ1.0mm
- Capillary Position Capacity
- 4
- Magnification of Lens
- 20x
- Detection Method
- Fully automatic
The advanced features and familiar interface of the automatic melting point apparatus make it ideal for your pharmaceutical, raw materials and quality control applications.
Added to your inquiry list. It travels with your next quote request.
3 models
Product Description
Melting Point Apparatus specification across the range. Figures are the manufacturer’s published values.
| Model | MPA-70I | MPA-80 | MPA-90I |
|---|---|---|---|
| Capillary Size | Outer φ1.4mm, inner φ1.0mm | Outer φ1.4mm, inner φ1.0mm Outer φ 4mm, inner φ3.6mm | |
| Capillary Position Capacity | 4 | ||
| Magnification of Lens | 20x | ||
| Detection Method | Fully automatic | ||
| Display | 10-inch high-definition color screen | ||
| Temperature Range | RT-360℃ | RT-400℃ | RT-420℃ |
| Temperature Resolution | 0.1℃ | 0.01℃ | |
| Heating Rate | 0.1℃--20℃ (200 steps, infinitely adjustable) | ||
| Temperature Rising Resolution | 0.1℃ | 0.01℃ | |
| Heating Rate | 0.1℃/Min: 20℃/Min | ||
| Accuracy | ±0.2℃ (<200℃) ±0.4℃ (>200℃) | ±0.2℃ (<200℃) ±0.5℃ (>200℃) | |
| Temperature Control Method | PID precise temperature control | ||
| Video Function | Taking pictures and video | ||
| Video Replay | Yes | ||
| Storage Capacity | 32G | 64G | 128G |
| Graphic | 300 | 800 | |
| Communication Ports | USB, Wi-Fi, RS232 | ||
| Number of Managed Users | >300, four-level management | >500, three-level management | >500 |
| Audit Trial | Yes | ||
| Power Supply | 220V, 50Hz | ||
| Shipping Size (WxDxH)(mm) | 400x350x340 | ||
| Gross Weight (KG) | 6.5 | ||
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Automated integration to realize one-click measurement function.
- High-definition video replaces the traditional microscope with high visual field.
- Automatically record the melting range, initial melting and final melting.
- Export PDF and Excel data from USB flash drive, anti-tampering function.
- Optional printer to print data directly.
- Data retrieval function: The automatic melting point apparatus is convenient for users to quickly find the data they want in a large number of databases
- Semi-automatically record the melting range, initial melting and final melting.
- Data retrieval function: The melting point apparatus is convenient for users to quickly find the data they want in a large number of databases.
