Hotplates and Stirrers
- Models
- HC-G550
- Work Plate Size (WxD)
- 184x184mm (7 inch)
- Work Plate Material
- Glass ceramic
- Heating Position
- 1
- Heating Temperature Range
- Room temp. -550°C, increment 5°C
Hot plates are widely used in chemical, biological and pharmaceutical industries for heating operations during dissolution, distillation, extraction and other experimental processes.
Added to your inquiry list. It travels with your next quote request.
1 models
Product Description
Hotplates and Stirrers specification across the range. Figures are the manufacturer’s published values.
| Model | HC-G550 |
|---|---|
| Work Plate Size (WxD) | 184x184mm (7 inch) |
| Work Plate Material | Glass ceramic |
| Heating Position | 1 |
| Heating Temperature Range | Room temp. -550°C, increment 5°C |
| Control Accuracy of Work Plate | ±10°C |
| Safety Temperature | 580°C |
| Temperature Display | LED |
| Temperature Display Accuracy | ±1°C |
| External Temperature Sensor | PT1000(±0.5°C) |
| Residual Heat Warning Temperatur | 50°C |
| Protection Class | IP21 |
| Power | 1010W |
| Permissible Ambient Temperature and Humidity | 5-40°C, 80%RH |
| Voltage Frequency | 100-120/200-240V, 50/60Hz |
| Heating Power | 1000W |
| Sizes(W×D×H)(mm) | 360x215x112 |
| Shipping Size(W×D×H)(mm) | 490x350x260 |
| N.W./G.W. (kg) | 4.5/6 |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- LED screen shows temperature
- Max. temperature up to 550°C
- Separate safety circuits with fixed safety temperature of 580°C
- External temperature control is possible by connecting the temperature sensor (PT 1000) with an accuracy at ±0.5°C
- Glass ceramic work plate provides excellent chemical-resistant performance and most efficient heat transfer
- After turning off the hotplate, if the residual temperature of the heating plate is too high (above 50°C), a residual heat warning will be issued and the "HOT" warning light will flash to prevent users from getting burned.
- DC brushless motor, capable of long-term operation;
- Wide voltage design, with a wide range of applications;
Next step
Tell us the capacity and the duty.
We will confirm the right model, the price and the lead time.
