Density Meter
- Models
- DME-120LE; DME-300LE; DME-120L; DME-300L
- Capacity
- 120 g
- Density Resolution
- 0.0001 g/cm³
- Density Range
- 0.0001–99.9999 g/cm³
- Measuring Principle
- Archimedes principle displacement method
The economic liquid densimeter offers precise measurements for solids, liquids, and powders.
Added to your inquiry list. It travels with your next quote request.
4 models
Product Description
Density Meter specification across the range. Figures are the manufacturer’s published values.
| Model | DME-120LE | DME-300LE | DME-120L | DME-300L |
|---|---|---|---|---|
| Capacity | 120 g | 300 g | 120 g | 300 g |
| Density Resolution | 0.0001 g/cm³ | 0.001 g/cm³ | 0.0001 g/cm³ | 0.001 g/cm³ |
| Density Range | 0.0001–99.9999 g/cm³ | 0.001–99.999 g/cm³ | 0.0001–99.9999 g/cm³ | 0.001–99.999 g/cm³ |
| Measuring Type | a: mobility liquid, viscous liquid, volatile liquid, corrosivity liquid, high temperature liquid, suspension liquid ,emulsion and so on | |||
| b: alcohol, scaling powder, essence, blood, sodium chloride, glycerol, electrolyte, diesel, refrigerating, hydrofluoric acid, dichloromethane, vitriol and so on. | ||||
| Measuring Principle | Archimedes principle displacement method | |||
| Measuring Mode | 1 group | |||
| Measuring Time | About 5 seconds | |||
| Sample Temperature Range | Room temperature to 100 ℃ | |||
| Memory Mode | Memory in shorter time by one procedure | |||
| Result Display | Density value | |||
| Specific Gravity Measuring Frame | Stainless steel specific gravity measuring frame | |||
| Setting Function | Temperature setting, solution density setting, measuring weights setting | |||
| Calibration | Auto correction with one button, auto detection. | |||
| Measuring Testing | Distilled testing | |||
| Output Interface | RS-232, output and print testing data conveniently | |||
| Standard Accessories | Measuring frame, standard liquid measuring assembly (2 pcs stainless steel pothooks, 1 pc glass weight, 1 pc stainless steel weight,2 pcs beakers), tweezer, thermometer,100g weight, wind and dust cover,measuring support, power transformer | |||
| Optional Accessories | Printer (can connect computer), anti-corrosive liquid measuring assembly | |||
| Additional Accessories | - | Stainless steel weights | ||
| - | Windshield | |||
| Measures liquids | - | Measures high-viscosity liquids or thick pastes, i.e., all fully flowable liquids | ||
| Power Supply | 220/110 V, 50/60 Hz | |||
| External Size (W×D×H) | 195×230×185 mm | |||
| Shipping Size (W×D×H) | 440×180×345 mm | |||
| N.W./G.W. | 1.5 / 3.1 kg | 1.5 / 4.5 kg | ||
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- 1. LCD display,data can be read directly.
- 2. Short measuring time, about 5s.
- 3. High accuracy of measuring.
- 4. Density value can be showed by one procedure. and it can measure repeatedly continuously rapid.
- 5. Simple operation, it does not need tedious debugging and operation, not affected by external factors and temperature compared with traditional wechsler balance method and pycnometer method densimeter, also stable and durable.
- 6. Very easy to clean measuring cup, and not limited by measuring diameter.
- 7. Take samples conveniently. and 50CC would be okay.
- 8. Coordinate with the operation of thermostatic tank to measure the proportion with the required temperature.
