Home/Products/Scitek Global/Cytotoxic Safety Cabinet
Safety & containment
Cytotoxic Safety Cabinet
- Models
- BSC-II-1100C; BSC-II-1300C; BSC-II-1800C
- External Size (W×D×H)(mm)
- 1087×760×2100
- Internal Size (W×D×H)(mm)
- 910×600×630
- Tested Opening
- Safety height 200 mm (8")
- Max Opening
- 440 mm
This cytotoxic safety cabinet is designed to provide a sterile environment for the handling and preparation of cytotoxic drugs used in chemotherapy.
Added to your inquiry list. It travels with your next quote request.
3 models
Product Description
Cytotoxic Safety Cabinet specification across the range. Figures are the manufacturer’s published values.
| Model | BSC-II-1100C | BSC-II-1300C | BSC-II-1800C | |
|---|---|---|---|---|
| External Size (W×D×H)(mm) | 1087×760×2100 | 1380×760×2100 | 1880×760×2100 | |
| Internal Size (W×D×H)(mm) | 910×600×630 | 1220×600×630 | 1700×600×630 | |
| Tested Opening | Safety height 200 mm (8") | |||
| Max Opening | 440 mm | |||
| Work Surface Height | 800 mm | |||
| Control System | Display | 7 inch LCD Touch Screen, Microprocessor; | ||
| Humidity and temperature can be displayed on the control panel. | ||||
| Alarm | Abnormal airflow velocity, Filter replacement, Front window at unsafe height, High filter pressure alarm | |||
| Airflow System | Downflow Velocity | 0.33m/s±0.025m/s | ||
| Inflow Velocity | 0.53m/s±0.025m/s | |||
| Exhaust Air Volume | 347 m³/h | 465 m³/h | 648 m³/h | |
| Air filtration System | Supply Filter | ULPA filter, efficiency>99.9995% for particle size at 0.1–0.3 μm | ||
| Exhaust Filter | ULPA filter: first exhaust filter: 0.1–0.3 μm efficiency 99.9995%; | |||
| HEPA filter: secondary exhaust filter: 0.3 μm efficiency 99.995% | ||||
| Cabinet Construction | Main Body | Cold-rolled steel with anti-bacteria powder coating | ||
| Work Surface | 304 stainless steel | |||
| Front Window | Motorized, tempered glass ≥6 mm, anti-UV | |||
| Electrical System | UV Lamp | 20W×1 | 30W×1 | 40W×1 |
| Emission of 253.7 nanometers for most efficient decontamination UV life indicator, UV timer | ||||
| LED Lamp | 12W×2 | 16W×2 | 16W×2 | |
| Waterproof Socket | Two, total load of two sockets: ≤500W | |||
| Consumption | 700 W | 900 W | 1300 W | |
| Not include socket loading power consumption | ||||
| Power Supply | AC 220±10% V, 50/60 HZ; 110±10% V, 60 Hz | |||
| Illumination | ≥1000 Lux | |||
| Sound Emission | ≤67 dB | |||
| Standard Accessory | 1. Base Stand | |||
| 2. Drain Valve; | ||||
| 3. Waterproof Sockets×2; | ||||
| 4. LED Lamp×2; | ||||
| 5. UV Lamp×1; | ||||
| 6. Water Tap×1; | ||||
| 7. Gas Tap×1; | ||||
| 8. Footmaster Caster; | ||||
| 9. Air Velocity Sensor | ||||
| Optional Accessory | Side windows | |||
| Gross Weight (kg) | Main Unit: 290 Bottom filter part: 70 | Main Unit: 335 Bottom filter part: 80 | Overall: 470 | |
| Shipping Size (W×D×H)(mm) | Main Unit: 1210×1080×1770 Bottom filter part:1090×550×860 | Main Unit: 1420×1080×1770 Bottom filter part: 1290×550×860 | Overall: 2060×910×2310 | |
| Shipping Volume (m³) | 2.83 | 3.3 | 4.4 | |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Ergonomic control panel location, centered and angled down for an easy reach & viewing.
- Made of solid psychological board, resistant to strong acid and alkali.
- The non-direct light source design can effectively relieve the operator's visual fatigue under the condition of ensuring the illumination.
- Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.
- Front sliding sash interlock with fan and UV lamp.
- UV sterilization with UV lamp timing function.
- Front sash and side windows are made of UV-resistant tempered glass.
- The host and sockets have independent capacitors to prevent current overload.
Applications
Where it is used
- Preparation and compounding of antitumor drugs
- Virus and genotoxicity experiments
- Microbiology and molecular biology research
- Gene editing experiments (such as CRISPR/Cas9 experiments)
- Handling of high-risk reagents in pharmaceutical and biotechnology experiments
- Horizontal laminar flow cabinet is equipped with advanced features and precise controls, laminar flow cabinets find a wide variety of applications in environments where aseptic and controlled workspaces are critical.
- Ideal for microbiological research laboratories, they provide aseptic conditions for microbiological cultures, culture substrate preparation and sample processing.
