Constant Temperature and Humidity Incubator
- Models
- ICB-80THP; ICB-150THP; ICB-250THP; ICB-350THP; ICB-460THP
- Capacity(L)
- 80
- Display
- 5.6-inch touch screen
- Circulation Mode
- Forced convection
- Size (W×D×H)(mm)
- Internal
The constant temperature & humidity incubator is used in laboratory research to provide a constant growth environment to promote cell growth.
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Constant Temperature and Humidity Incubator specification across the range. Figures are the manufacturer’s published values.
| Model | ICB-80THP | ICB-150THP | ICB-250THP | ICB-350THP | ICB-460THP | |
|---|---|---|---|---|---|---|
| Capacity(L) | 80 | 150 | 250 | 350 | 460 | |
| Display | 5.6-inch touch screen | |||||
| Circulation Mode | Forced convection | |||||
| Size (W×D×H)(mm) | Internal | 400×400×500 | 400×500×750 | 500×550×910 | 600×600×1000 | 650×650×1100 |
| External | 625×550×1065 | 600×660×1360 | 720×710×1570 | 800×760×1610 | 850×810×1715 | |
| Temperature | Range (℃) | 0–65 | ||||
| Fluctuation (℃) | High Temp. : ±0.5°C, Low Temp. :±1°C | |||||
| Resolution (℃) | 0.1 | |||||
| Uniformity (℃) | ±1 | |||||
| Sensor | PT100 | |||||
| Humidity | Rang | 30%–95%RH | ||||
| Stability | ±3%RH | |||||
| Method | Built-in ultrasonic humidifier | |||||
| Sensor | High precision anti-condensation | |||||
| Controller | PID | |||||
| Timer | 0-99h59min/99×5Segments (with timing waiting function) | |||||
| Material | Internal | 304 stainless steel | ||||
| External | Cold rolled steel electrostaticspraying exterior | |||||
| Test Hole | Standard Φ43mm test hole on the left side | |||||
| External Socket | Universal socket(one) | |||||
| Compressor | Variable frequency compressor (energy-saving) | |||||
| Refrigerant | R134a (CFC free) | |||||
| Defrosting Mode | Automatic | |||||
| Safety Device | Over temperature, over humidity, water shortage alarm | |||||
| Power Supply | AC 220/110V, 50/60Hz | |||||
| Shelves | 2 | |||||
| Consumption (W) | 600 | 800 | 1000 | 1200 | 1400 | |
| G.W. (kg) | 61 | 88 | 112 | 139 | 168 | |
| Shipping Size (W×D×H)(mm) | 690×620×1150 | 770×735×1520 | 820×800×1660 | 870×860×1800 | 990×1040×1970 | |
| Standard | USB port for storing and exporting data | |||||
| Optional | RS485 interface, printer and spare shelf | |||||
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- 304 Stainless steel chamber, semi-circular inner corner, shelves can be freely loaded and unloaded, easy to clean.
- The shell is treated with electrostatic spraying technology, which is corrosion-resistant and durable.
- Large touch screen, 99×5-segment program control, with temperature curve, data storage function.
- Inverter compressor, balanced control of cooling and heating, small temperature fluctuation, precise temperature control.
- Double-layer door structure, the inner door uses tempered glass for easy observation of samples, and the outer door uses magnetic strips for good sealing and heat preservation performance.
- Intelligent defrosting, with compressor overheat protection, instrument failure, automatic water inlet and water shortage alarm protection, etc.
- Built-in humidification system, imported humidity sensor components, automatic humidity control, good stability and high precision.
- Stainless steel chamber, semi-circular inner corner, shelves can be freely loaded and unloaded, easy to clean.
