Benchtop Ion Meter
- Models
- I300F; I500T; ION-B931
- Parameters
- pH/ISE/Temp.(mV/pX)
- pH — Range
- -2.00 to 20.00 pH
- pH — Resolution
- 0.1, 0.01 pH
- pH — Accuracy
- ±0.01 pH
Professional pH and ion meter, 5 points calibration, setup menu contains 20 options. The benchtop ion meter is suitable for measuring the pH, mV, ion concentration, etc.
Added to your inquiry list. It travels with your next quote request.
3 models
Product Description
Benchtop Ion Meter specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| I300F — Benchtop Ion Meter, 5 Calibration Points | |
| Parameters | pH/ISE/Temp.(mV/pX) |
| pH — Range | -2.00 to 20.00 pH |
| pH — Resolution | 0.1, 0.01 pH |
| pH — Accuracy | ±0.01 pH |
| pH — Calibration Points | Up to 5 |
| pH — Standard Customization | Yes |
| pH — Standard Recognition | NIST, GB, DIN, USA buffers |
| mV — Range | -2000.0 to 2000.0 mV |
| mV — Resolution | 0.1 mV |
| mV — Accuracy | ±0.3 mV or ±0.1% of reading whichever is greater |
| pX — Range | -2.00 to 20.00 pX |
| pX — Resolution | 0.1, 0.01 pX |
| pX — Accuracy | ±0.01 pX |
| pX — Calibration Points | Up to 5 |
| ISE — Range | 1.000e-9 to 9.999e+9 |
| ISE — Unit | mol/L, mmol/L, g/L, mg/L, µg/L, ppm, ppb |
| ISE — Resolution | Up to 4 significant digits |
| ISE — Accuracy | ±0.3% |
| ISE — Calibration Points | Up to 5 |
| Temperature — Range | -5.0 to 110 ºC, 23.0 to 230 ºF |
| Temperature — Unit | ºC, ºF |
| Temperature — Resolution | 0.1 |
| Temperature — Accuracy | ±0.2ºC |
| Measurement — Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement — Reading Prompts | Reading, Stable, Locked |
| Measurement — Temp. Compensation | ATC, MTC |
| Data management — Data Storage | 500 results each |
| Data management — GLP Features | Yes |
| Inputs — pH Electrode | BNC(Q9) |
| Inputs — Temp. Probe | 4-pin aviation connector |
| I500T — Benchtop Ion Meter, 6 Points | |
| Parameters | pH/ISE/Temp.(mV/ORP/pX) |
| pH — Range | -2.000 to 20.000 pH |
| pH — Resolution | 0.1, 0.01, 0.001pH |
| pH — Accuracy | ±0.002 pH |
| pH — Calibration Points | Up to 6 |
| pH — Standard Customization | Yes |
| pH — Calibration Reminder | Yes |
| pH — Standard Recognition | NIST, GB, DIN, USA, MERK, JIS buffers |
| pH — Slope Limit | Yes |
| mV/ORP — Range | -2000.00 to 2000.00 mV |
| mV/ORP — Resolution | 0.1, 0.01 mV |
| mV/ORP — Accuracy | ±0.1 mV or ±0.03% |
| mV/ORP — EH ORP Mode | Yes |
| mV/ORP — ORP Calibration Points | 1 custom point (relative mV) |
| pX — Range | -2.000 to 20.000 pX |
| pX — Resolution | 0.1, 0.01, 0.001 pX |
| pX — Accuracy | ±0.002 pX |
| pX — Calibration Points | Up to 6 |
| ISE — Range | 1.000e-9 to 9.999e+9 |
| ISE — Units | mol/L, mmol/L, g/L, mg/L, µg/L, ppm, ppb |
| ISE — Resolution | Up to 4 significant digits |
| ISE — Accuracy | ±0.3% |
| ISE — Calibration Points | Up to 6 |
| Temperature — Range | -10 to 135 ºC, 14 to 275 ºF |
| Temperature — Unit | ºC, ºF |
| Temperature — Resolution | 0.1 |
| Temperature — Accuracy | ±0.1 |
| Measurement — Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement — Reading Prompts | Reading, Stable, Locked |
| Measurement — Temp. Compensation | ATC, MTC |
| ION-B931 — Benchtop Ion Meter 2 to 5 Points Calibration | |
| Range | 0.001~19999 (depending on the range of ISE) |
| Resolution | 0.001, 0.01, 0.1, 1 |
| Accuracy | ±0.5% F.S. (monovalent), ±1% F.S. (divalent) |
| Measurement Units | ppm, mg/L, mol/L, mmol/L |
| Calibration Points | 2 to 5 points |
| Calibration Solutions | 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000 |
| mV Range | ±1999.9mV |
| Resolution | 0.1, 1mV, selectable |
| Accuracy | ±0.2mV |
| Range | 0~105°C/32~221°F |
| Resolution | 0.1°C/0.1°F |
| Accuracy | ±0.5°C/±0.9°F |
| Offset Calibration | 1 point, reading ±10°C |
| Temperature Compensation | 0~100°C, manual or automatic |
| Stability Criteria | Low or high |
| Calibration Due Alarm | 1 to 31 days or off |
| Slope/Offset Display | Yes |
| Hold Function | Manual or auto-endpoint |
| Memory | 500 data sets |
| Communication Interface | USB |
| Connector | BNC, 3.5mm jack socket |
| Display | Custom LCD(125x100mm) |
| Power Requirements | DC5V power adapter |
| Sizes(W×D×H) | 210×188×60 |
| Shipping Size (W×D×H)(mm) | 300x250x200 |
| N.W./G.W. (kg) | 1.5/2 |
Specification published by Scitek Global. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- High resolution LCD display, 5.7 inches.
- Multi-reading feature allows auto-read, timed-read and continuous-read.
- Automatic/Manual temperature compensation ensures accurate results.
- Auto-hold feature senses and locks the measurement endpoint.
- Data Storage 500 sets (GLP-compliant).
- Support for USB or RS-232 communication.
- Reset feature automatically resumes all settings back to factory default options.
- IP54 waterproof.
- 1-5 points calibration with Standard Recognition.
- Selectable pH buffer groups, including NIST, DIN, GB, USA.
