Heating, cooling & storage
Vacuum Oven
- Models
- LVO-A10; LVO-A11; LVO-A12; LVO-A13; LVO-A14
- Chamber volume
- 215 L
- Temperature range
- RT+10 to 200°C
- Temperature resolution
- 0.1°C
- Temperature stability
- ±1°C
Vacuum Oven LVO-A10 come with amazing features like Ambient temperature with 5 to 40°C, Chamber volume with 215 L, Display with LED Display, Exterior dimension (W × D × H) with 720 × 820 ×17…
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Vacuum Oven specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LVO-A10 — Vacuum Oven | |
| Chamber volume | 215 L |
| Temperature range | RT+10 to 200°C |
| Temperature resolution | 0.1°C |
| Temperature stability | ±1°C |
| Display | LED Display |
| Vacuum Pump | Yes, Standard Accessory |
| Vacuum Degree | 133 Pa |
| Observation window | Dual layered tempered glass |
| Chamber material | Stainless Steel 304 |
| Shelves | 3pcs (Independent temp. control) |
| Shelves material | Aluminum tray |
| Ambient temperature | 5 to 40°C |
| Power | 2100 W |
| Power supply | AC 220 V, 50 Hz |
| Interior dimension (W × D × H) | 560 × 600 ×640 mm |
| Exterior dimension (W × D × H) | 720 × 820 ×1750 mm |
| Packing dimension (W × D × H) | 900 × 840 × 1750 mm |
| Gross weight | 313 kg |
| LVO-A11 — Vacuum Oven | |
| Chamber volume | 90 L |
| Temperature range | RT+10 to 200°C |
| Temperature resolution | 0.1°C |
| Temperature stability | ±1°C |
| Display | LCD Display |
| Vacuum Pump | Yes, Standard Accessory |
| Vacuum Degree | 133 Pa |
| Observation window | Tempered glass |
| Chamber material | Stainless Steel 304 |
| Shelves | 2 pcs (Independent temp. control) |
| Shelves material | Aluminum tray |
| Ambient temperature | 25 °C |
| Power | 1600 W |
| Power supply | AC 220 V, 50 Hz |
| Interior dimension (W × D × H) | 450 × 450 × 450 mm |
| Exterior dimension (W × D × H) | 610 × 660 × 1450 mm |
| Packing dimension (W × D × H) | 730 × 760 × 1470 mm |
| Net weight | 110 kg |
| Gross weight | 176 kg |
| LVO-A12 — Vacuum Oven | |
| Chamber Volume | 10 L |
| Number of Shelves | 2 pcs |
| Temperature Range | RT + 10°C to 200°C |
| Temperature Display Resolution | 0.1 |
| Controller | LED display |
| Temperature Stability | ± 1°C |
| Vacuum Degree | 133 Pa |
| Ambient Temperature | +5°C to 40°C |
| Power Supply | AC 220 V 50 Hz |
| Power Consumption | 400 W |
| Interior Dimensions | 220 × 210 × 220 mm |
| Exterior Dimensions | 500 × 375 × 410 mm |
| Gross Weight | 40 kg |
| LVO-A13 — Vacuum Oven | |
| Chamber Volume | 24 L |
| Number of Shelves | 1 pc |
| Temperature Range | RT + 10°C to 200°C |
| Temperature Display Resolution | 0.1 |
| Controller | LED display |
| Temperature Stability | ± 1°C |
| Vacuum Degree | 133 Pa |
| Ambient Temperature | +5°C to 40°C |
| Power Supply | AC 220 V 50 Hz |
| Power Consumption | 400 W |
| Interior Dimensions | 300 × 300 × 275 mm |
| Exterior Dimensions | 605 × 490 × 450 mm |
| Gross Weight | 56 kg |
| LVO-A14 — Vacuum Oven | |
| Chamber Volume | 50 L |
| Number of Shelves | 2 pcs |
| Temperature Range | RT + 10°C to 200°C |
| Temperature Display Resolution | 0.1 |
| Controller | LED display |
| Temperature Stability | ± 1°C |
| Vacuum Degree | 133 Pa |
| Ambient Temperature | +5°C to 40°C |
| Power Supply | AC 220 V 50 Hz |
| Power Consumption | 1450 W |
| Interior Dimensions | 415 × 370 × 345 mm |
| Exterior Dimensions | 720 × 560 × 550 mm |
| Gross Weight | 96 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Designed with vacuum pump as standard accessory
- Independent temperature controlling shelves
- Microprocessor controller with timing function
- Designed with LED Display
- Dual layer tempered glass door for clear observation
- Chamber is made up of Stainless steel material
- Minimum heating time 50 % less than traditional vacuum oven
- Equipped with independently displayed and controlled temperature in setting
Applications
Where it is used
- Vacuum Oven used for drying of thermo-sensitive, oxidative materials easily. It can be filled with inert gases for a rapid drying of some compound material.
- Our Vacuum Oven LVO-A12 is well-suited for efficient drying of thermosensitive, oxidative, and easily decomposable materials in laboratory and industrial settings. It can also be used with inert gas to safely dry compound materials, ensuring clean and controlled processing.
- Vacuum Oven LVO-A13 is suitable for gentle drying of thermosensitive, oxidative, and easily decomposable materials in both laboratory and industrial environments. It also supports inert gas purging, making it appropriate for the safe and controlled drying of compound materials.
- Our Vacuum Oven LVO-A14 is well-suited for efficient drying of thermosensitive, oxidative, and easily decomposable materials in laboratory and industrial settings. It can also be used with inert gas to safely dry compound materials, ensuring clean and controlled processing.
Next step
Tell us the capacity and the duty.
We will confirm the right model, the price and the lead time.
