Touch Screen Melting Point Apparatus
- Models
- LDMP-A12; LDMP-A13; LDMP-A20; LDMP-B10; LDMP-B11
- Temperature Range
- RT to 320°C
- Cooling Function
- NO
- Sample Cell
- Capillary tube
- Sample Tube
- External diameter: 1.6 mm internal diameter: 1.2 mm
Labtron’s Melting Point Apparatus LDMP-A12 offers a maximum temperature of 320°C for reliable results.
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Touch Screen Melting Point Apparatus specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LDMP-A12 — Melting Point Apparatus | |
| Temperature Range | RT to 320°C |
| Cooling Function | NO |
| Sample Cell | Capillary tube |
| Sample Tube | External diameter: 1.6 mm internal diameter: 1.2 mm |
| Resolution | 0.1°C |
| Temperature Increase Speed | 0.1°C to 10°C (100 temperature point infinitely adjustable) |
| Temperature Control Method | PID control temperature, Fully closed design of furnace body |
| Accuracy | ±0.4°C (˂ 250°C), ± 0.7°C (˃ 250°C) |
| Repeatability | When 0.1°C/Min, repeatability ± 0.3°C |
| Display | FTF high resolution Colourful touch screen |
| Output | RS 232 interface |
| Dimension | 250 mm × 250 mm × 150 mm |
| Power consumption | 100 W |
| Power Supply | 100 V to 240 V, 50 Hz to 60 Hz |
| Weight | 1.2 kg |
| LDMP-A13 — Melting Point Apparatus | |
| Temperature Range | RT to 400°C |
| Cooling Function | Built-in Cooling Fan |
| Sample Cell | Capillary tube |
| Sample Tube | External diameter: 1.6 mm internal diameter: 1.2 mm |
| Resolution | 0.1°C |
| Temperature Increase Speed | 0.1°C to 10°C (100 temperature point infinitely adjustable) |
| Temperature Control Method | PID control temperature, Fully closed design of furnace body |
| Accuracy | ±0.4°C (˂ 250°C), ± 0.7°C (˃ 250°C) |
| Repeatability | When 0.1°C/Min, repeatability ± 0.3°C |
| Display | FTF high resolution Colourful touch screen |
| Output | RS 232 interface |
| Dimension | 250 mm × 250 mm × 150 mm |
| Power consumption | 100 W |
| Power Supply | 100 V to 240 V, 50 Hz to 60 Hz |
| Weight | 1.2 kg |
| LDMP-A20 — Melting Point Apparatus | |
| Temperature range | Room temperature to 350 ℃ |
| Detection mode | Fully automatic (compatible with manual) |
| Processing capacity | 4 / batch |
| Judgment ability | Automatically judge color samples |
| Capillary size | Outer diameter 1.4 mm, Inner diameter 1.0 mm |
| Temperature resolution | 0.1 ℃ |
| Temperature control mode | PID precise temperature control |
| Heating rate | 0.1 ℃ / min or 20 ℃ / min |
| Accuracy | ± 0.3 ℃ ( 200℃） |
| Repeatability | Melting point repeatability ± 0.1 ℃ at 0.1 ℃ / min |
| Exploration mode | Yes |
| Magnification | ≥ 10 |
| Video function | Take photos |
| Video playback | With / with time watermark |
| HD camera | Observe the melting state of sample |
| Storage space | 16 g hard disk, ≥ 2G memory |
| Test method | Yes |
| Atlas preservation | 200 |
| Continuous shooting time | 50 minutes |
| Experimental scheme | 50 sets |
| Display mode | 8 inch high-definition color screen |
| Data interface | USB, network Wi-Fi interface, RS232 |
| Printer | Laser printer or thermal / needle type (compatible) |
| Power consumption | 120 W |
| Power supply | 220 V, 50 Hz |
| Dimension | 350*220*220 mm |
| LDMP-B10 — Melting Point Apparatus | |
| Temperature control range | RT to 100℃ |
| Detection method | Semi-automatic |
| Capacity per batch | 2 pcs/batch |
| Temperature resolution | 0.1℃ |
| Temperature gradients | (0.1 to 10.0)℃/Min |
| Temperature accuracy | ±0.3℃ |
| Repeatability | 0.1℃/Min , ±0.1℃ |
| Camera & Video | Camera |
| Video playback | NA |
| Operator account | NA |
| Result storage | 200 |
| SD card capacity | 8G |
| Display | TFT Touch screen |
| Interface | USB RS232 SD card Enternet |
| Opening capillary size | I.D>1.0 mm, O.D.1.4 mm Double opening |
| Power | 110 to 220V 50, 60HZ 120W |
| Dimension | 400 × 280× 330 mm |
| Weight | 5 kg |
| LDMP-B11 — Melting Point Apparatus | |
| Temperature control range | 6 to 100℃ |
| Detection method | Semi-automatic |
| Capacity per batch | 2 pcs/batch |
| Temperature resolution | 0.1℃ |
| Temperature gradients | (0.1 to 10.0)℃/Min |
| Temperature accuracy | ±0.3℃ |
| Repeatability | 0.1℃/Min , ±0.1℃ |
| Camera & Video | Camera & Video |
| Video playback | Yes |
| Operator account | 8 |
| Result storage | 400 |
| SD card capacity | 8G |
| Display | TFT Touch screen |
| Interface | USB RS232 SD card Enternet |
| Opening capillary size | I.D>1.0 mm, O.D.1.4 mm Double opening |
| Power | 110 to 220V 50, 60HZ 120W |
| Dimension | 400 × 280× 330 mm |
| Weight | 5 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Colourful touch screen display
- Increasing temperature speed can easily set from 0.1 to 10°C/ min
- Microprocessor PID temperature controlled system
- High resolution microscope lenses can observe sample clearly
- Display Test Mode: Can clearly see 3 samples melting situation and get 3 samples individual and average value
- Easy setting to pre-set temperature, heating rate, stop temperature
- Built-in cooling fan can easily cool down temperature and test next samples
- Fully closed design of furnace body to avoid any fire hazard for the user
Applications
Where it is used
- Melting Point Apparatus is widely using in chemical industry and medicine, it is necessary in instrument for the production of food, drugs, spices, dyes and other organic crystal substances.
- Melting Point Apparatus is used in Chemical, pharmaceutical, food and drug manufacturing and research industry for quality and testing purpose. It is also used in cosmetics, dye and paint production and testing plants, laboratories.
- It finds application across finding meting point of oil and fat in food and drug industry, biochemistry, medicines, mining, water management industry.
