Spectroscopy
Single Beam UV-Visible Spectrophotometer
- Models
- LUS-A10; LUS-A11; LUS-A50; LUS-A51; LUS-A52
- Wavelength Range
- 190 ~ 1100 nm
- Spectral Bandwidth
- 1 nm
- Wavelength Accuracy
- ± 0.3 nm
- Wavelength Repeatability
- 0.2 nm
Single Beam UV-Visible Spectrophotometer LUS-A10 come with amazing features like Baseline Flatness with ± 0.001 A, Data Output Port with USB, Detector with Silicon Photodiode, Light Source w…
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Single Beam UV-Visible Spectrophotometer specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LUS-A10 — Single Beam UV-Visible Spectrophotometer | |
| Wavelength Range | 190 ~ 1100 nm |
| Spectral Bandwidth | 1 nm |
| Wavelength Accuracy | ± 0.3 nm |
| Wavelength Repeatability | 0.2 nm |
| Photometric Range | 0 - 200 % T, (-0.3) to (-3.0) A, 0 - 9999 C |
| Photometric Accuracy | ± 0.3 % T |
| Photometric Repeatability | 0.2 % T |
| Detector | Silicon Photodiode |
| Light Source | Deuterium & Tungsten Halogen Lamp |
| Stray Light | ≤ 0.05 % T at 220 nm, 360 nm |
| Stability | 0.002 A / h at 500 nm |
| Data Output Port | USB |
| Power Requirement | AC 220 V / 50 Hz, 110 V / 60 Hz. |
| Noise | ± 0.001 A |
| Optical System | Single Beam (1200 lines / mm grating) |
| Baseline Flatness | ± 0.001 A |
| Printer Port | Parallel Port |
| Packing Size | 860 x 660 x 465 mm |
| Packing Weight | 35 kg |
| LUS-A11 — Single Beam UV-Visible Spectrophotometer | |
| Wavelength Range | 190 ~ 1100 nm |
| Spectral Bandwidth | 1.8 nm |
| Wavelength Accuracy | ± 0.3 nm |
| Wavelength Repeatability | 0.2 nm |
| Photometric Range | 0 - 200 % T, (-0.3) to (-3.0) A, 0 - 9999 C |
| Photometric Accuracy | ± 0.3 % T |
| Photometric Repeatability | 0.2 % T |
| Detector | Silicon Photodiode |
| Light Source | Deuterium & Tungsten Halogen Lamp |
| Stray Light | ≤ 0.05 % T at 220 nm, 360 nm |
| Stability | 0.002 A / h at 500 nm |
| Data Output Port | USB |
| Power Requirement | AC 220 V / 50 Hz, 110 V / 60 Hz. |
| Noise | ± 0.001 A |
| Optical System | Single Beam (1200 lines / mm grating) |
| Baseline Flatness | ± 0.001 A |
| Printer Port | Parallel Port |
| Packing Size | 860 x 660 x 465 mm |
| Packing Weight | 35 kg |
| LUS-A50 — Single Beam UV-Visible Spectrophotometer | |
| Optical System | Single Beam, Grating 1200 lines/mm |
| Wavelength Range | 190nm to 1100 nm |
| Spectral Bandwidth | 2 nm |
| Wavelength Accuracy | ± 0.1 nm at 656.1 nm, ± 0.3 nm at all |
| Wavelength Repeatability | Less than or equal to 0.1 nm |
| Photometric Accuracy | 0.2%T (0 to 100%T), ±0.0024A (0 to 0.5A), ±0.004A (0.5 to 1A) |
| Photometric Repeatability | Less than or equal to 0.15%T (0 to 100%T), 0.001A (0 to 0.5A), 0.002A (0.5 to 1A) |
| Photometric Range | 0-200%T, -0.3 to 3.4A, 0 to 9999C (0 to 9999F) |
| Stray Light | Less than or equal to 0.03%T at 220 nm, 360 nm |
| Stability | ±0.0003A/h at 500 nm |
| Baseline Flatness | ±0.001A |
| Noise | 0.0005A at 500 nm |
| Work Mode | T, A, C, E |
| Scanning Speed | Hi, Med, Low (Max 3000 nm/min) |
| Wavelength Setting | Auto |
| Display | 10.1" TFT Colored Capacitive Touch Screen |
| Light Source | Imported Deuterium & Tungsten lamp |
| Detector | Imported Silicon Photodiode |
| Cuvette Holder | 10 mm manual 4-cell holder |
| Output | USB drive, USB host, RS232 |
| Power Supply | AC 220V/50Hz or AC 110V/60Hz |
| Shipping Size | 810mm × 660mm × 390mm |
| Gross Weight | 26 kg |
| LUS-A51 — Single Beam UV-Visible Spectrophotometer | |
| Optical System | Single Beam, Grating 1200 lines/mm |
| Wavelength Range | 190nm to 1100 nm |
| Spectral Bandwidth | 1 nm |
| Wavelength Accuracy | ± 0.1 nm at 656.1 nm, ± 0.3 nm at all |
| Wavelength Repeatability | Less than or equal to 0.1 nm |
| Photometric Accuracy | 0.2%T (0 to 100%T), ±0.0024A (0 to 0.5A), ±0.004A (0.5 to 1A) |
| Photometric Repeatability | Less than or equal to 0.15%T (0 to 100%T), 0.001A (0 to 0.5A), 0.002A (0.5 to 1A) |
| Photometric Range | 0-200%T, -0.3 to 3.4A, 0 to 9999C (0 to 9999F) |
| Stray Light | Less than or equal to 0.03%T at 220 nm, 360 nm |
| Stability | ±0.0003A/h at 500 nm |
| Baseline Flatness | ±0.001A |
| Noise | 0.0005A at 500 nm |
| Work Mode | T, A, C, E |
| Scanning Speed | Hi, Med, Low (Max 3000 nm/min) |
| Wavelength Setting | Auto |
| Display | 10.1 |
| Light Source | Imported Deuterium & Tungsten lamp |
| Detector | Imported Silicon Photodiode |
| Cuvette Holder | 10 mm manual 4-cell holder |
| Output | USB drive, USB host, RS232 |
| Power Supply | AC 220V/50Hz or AC 110V/60Hz |
| Shipping Size | 810mm × 660mm × 390mm |
| Gross Weight | 26 kg |
| LUS-A52 — Single Beam UV-Visible Spectrophotometer | |
| Wavelength range | 190 to 1100 nm |
| Spectral bandwidth | 0.5/1/2/4/5 nm |
| Wavelength Accuracy | ± 0.1nm @ 656.1 nm, ± 0.3 nm @ all |
| Wavelength Repeatability | ≤ 0.1 nm |
| Optical system | Single beam 1200 lines/mm |
| Photometric Range | 0 to 200 %T, -0.3 to 3A, 0 to 9999 C (0 to 9999F) |
| Photometric Accuracy | 0.2%T (0 to 100 %T), ±0.002A(0 to 0.5 A), ±0.004A (0.5 to 1 A) |
| Photometric Repeatability | ≤0.15 % T (0 to 100 %T), 0.001A (0 to 0.5A), 0.002A (0.5 to 1A) |
| Detector | Imported silicon photodiode |
| Light source | Imported Deuterium and Tungsten lamp |
| Stray light | ≤ 0.03 % T @ 220 nm, 360 nm |
| Stability | ± 0.0005 A/h @ 500 nm |
| Data Output Port | USB drive, USB host, RS232 |
| Power supply | AC 220 V, 50 Hz or 110 V, 60 Hz |
| Noise | 0.0005 A @ 500 nm |
| Display | 10.1 inches TFT colored capacitive touch screen |
| Baseline flatness | ± 0.001 A |
| Printer port | Parallel port |
| Work mode | T, A, C, E |
| Scanning speed | Hi, Med, Low (Max. 3000 nm/min) |
| Wavelength setting | Auto |
| Cuvette holder | 10 mm manual 4 cell holder |
| Dimension | 810 × 660 × 390 mm |
| Gross weight | 27 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Single beam spectrophotometer
- Wavelength range 190nm – 1100nm
- Spectral bandwidth 1nm
- Optical system with 1200 lines/mm grating
- Deuterium & Tungsten Halogen Lamp as dual light source
- 6 inches LCD (320x240 Dots) display & integrated user interface
- 4 cell holder available along with USB port for data storage
- Spectral bandwidth 1.8nm
Applications
Where it is used
- Single Beam UV-Visible Spectrophotometer is ideal for quality control, general research, pharmaceuticals, biochemical and clinical laboratory applications.
- Our Single Beam UV-Visible Spectrophotometer LUS-A50 offers precise absorbance and transmittance analysis across various wavelength range, ideal for laboratory research, pharmaceutical testing, and quality control applications.
- Our Single Beam UV-Visible Spectrophotometer LUS-A51 ensures precise absorbance, transmittance, and concentration analysis in laboratories, pharmaceutical research, and quality control applications with intuitive operation.
- Single Beam UV-Visible Spectrophotometer is used in high requirement for precision measurement in the research and production of organic chemistry, biochemistry, medical testing, food testing, environmental protection, water testing industries, etc.
