Muffle Furnace
- Models
- LMF-A10; LMF-C41; LMF-D10; LMF-I10; LMF-C33
- Max. Temperature
- 950 °C
- Capacity
- 3 L
- Heating Program
- Direct
- Thermal Rate
- 5°C - 25°C / min
Muffle Furnace LMF-A10 come with amazing features like Max. Temperature with 950 °C, Capacity with 3 L, Heating Program with Direct, Thermal Rate with 5°C - 25°C / min, Heating Element with…
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Muffle Furnace specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LMF-A10 — Muffle Furnace | |
| Max. Temperature | 950 °C |
| Capacity | 3 L |
| Heating Program | Direct |
| Thermal Rate | 5°C - 25°C / min |
| Heating Element | Fe-Cr-Al |
| Program Memories | 1 |
| Thermocouple Type | K Type |
| Heating Element Placement | Embedded into brick walls |
| Inner Insulation Material | Insulating Fire Brick |
| Front Face Insulation Material | Ceramic Fibre Board |
| Door Insulation Material | Ceramic Fibre Board |
| Housing Material | Steel Sheet |
| Housing Coating | Epoxy powder coating |
| Chimney | Standard |
| Element Heating Protection | Heating element protection by resistance wires |
| Lockable Door Handle | Sidewards |
| Temperature Control Accuracy | ± 1 °C |
| Measurement Accuracy | ± 1 °C |
| Power | 1500 W |
| Max. Current | 7A |
| Inner Volume Temperature Homogenity | ± 10 °C |
| Inner Chamber Dimension (W x H x D) | 130 x 105 x 230 mm |
| Product Outer Dimension (W x H x D) | 336 x 434 x 533 mm |
| Gross Dimension (W x H x D) | 420 x 620 x 620 mm |
| Net Weight | 25 kg |
| Gross weight | 35 kg |
| LMF-C41 — Muffle Furnace | |
| Max. Temperature | 1200 °C |
| Capacity | 20 L |
| Heating Program | 4 steps |
| Thermal Rate | 3 °C - 20 °C |
| Heating element | Fe-Cr-Al |
| Program Memories | 4 |
| Thermocouple Type | K Type |
| Heating Element Placement | Embedded into brick walls |
| Front Face, Inner Insulation Material | Insulating Fire Brick |
| Door Insulation Material | Ceramic Fiber Board |
| Housing Material | Steel Sheet |
| Housing Coating | Epoxy powder coating |
| Chimney | Standard |
| Heating Element Protection | Heating element protection by resistance wires |
| Lockable Door Handle | Sidewards |
| Temperature Control Accuracy | ± 1 °C (can vary at low temperatures) |
| Measurement Accuracy | ± 1 °C |
| Inner Volume Temperature Homogeneity | ± 10 °C |
| Max. Current | 2 × 9 A |
| Power | 4.200 W |
| Inner Chamber Dimension (W × H × D) | 250 × 200 × 395 mm |
| Product Outer Dimension (W × H × D) | 546 × 668 × 790 mm |
| Gross Dimension (W × H × D) | 606 × 950 × 728 mm |
| Net Weight | 65 kg |
| Gross weight | 85 kg |
| LMF-D10 — 1250°C Muffle Furnace | |
| Max. Temperature | 1250 °C |
| Capacity | 5 L |
| Heating Program | 2 step |
| Thermal Rate | 3 °C - 20 °C |
| Heating element | Fe-Cr-Al |
| Program Memories | 2 |
| Thermocouple Type | K Type |
| Heating Element Placement | Embedded into brick walls |
| Inner Insulation Material | Insulating Fire Brick |
| Front Face Insulation Material | Insulating Fire Brick |
| Door Insulation Material | Ceramic Fibre Board |
| Housing Material | Steel Sheet |
| Housing Coating | Epoxy powder coating |
| Chimney | Standard |
| Heating Element Protection | None |
| Lockable Door Handle | Sidewards |
| Temperature Control Accuracy | ± 1 °C (can vary at low temperatures) |
| Measurement Accuracy | ± 1 °C |
| Inner Volume Temperature Homogenity | ± 10 °C |
| Auto Start at Certain Date | No |
| Max. Current | 10A |
| Power | 2.250 W |
| Inner Chamber Dimension (W x H x D) | 150 x 150 x 225 mm |
| Product Outer Dimension (W x H x D) | 446 x 618 x 620 mm |
| Gross Dimension ( W x H x D) | 506 x 780 x 678 mm |
| Net Weight | 49 kg |
| LMF-I10 — Muffle Furnace | |
| Max. Temperature | 1600 °C |
| Capacity | 4.5 L |
| Heating Program | 50 steps |
| Thermal Rate | 3 °C - 20 °C |
| Heating element | MoSi₂ (Molybdenum disilicide) |
| Program Memories | 50 |
| Thermocouple Type | B Type |
| Display | 4 x 20 |
| Heating Element Placement | Vertically aligned next to the side walls |
| Inner Insulation Material | Ceramic Fibre Board |
| Front Face Insulation Material | Insulating Fire Brick |
| Door Insulation Material | Ceramic Fibre Board |
| Housing Material | Steel Sheet |
| Housing Coating | Epoxy powder coating |
| Chimney | Standard without fan |
| Lockable Door Handle | Sidewards |
| Temperature Control Accuracy | ± 1 °C (can vary at low temperatures) |
| Measurement Accuracy | ± 1 °C |
| Inner Volume Temperature Homogenity | ± 10 °C |
| Auto Start at Certain Date | Yes |
| Show Remaining Waiting Time | Yes |
| Skip the Waiting Step | Yes |
| Burst Heating Mode | Yes |
| Max. Current | 18 A |
| Power | 4000W |
| Inner Chamber Dimension (W x H x D) | 150x150x200 mm |
| LMF-C33 — Muffle Furnace | |
| Max. Temperature | 1300 °C |
| Capacity | 10 L |
| Heating Program | 16 steps |
| Thermal Rate | 3 °C - 20 °C |
| Heating element | HRE electric resistance wire |
| Program Memories | 50 steps |
| Thermocouple Type | S Type |
| Heating Element Placement | Hanging ceramic tube through the resistance wire spring |
| Inner Insulation Material | Insulating Fire Brick |
| Front Face Insulation Material | Insulating Fire Brick |
| Door Insulation Material | Ceramic Fibre Board |
| Housing Material | Steel Sheet |
| Housing Coating | Epoxy powder coating |
| Heating Element Protection | Heating element protection by resistance wires |
| Lockable Door Handle | Sidewards |
| Temperature Control Accuracy | ± 1 °C (can vary at low temperatures) |
| Measurement Accuracy | ± 1 °C |
| Inner Volume Temperature Homogenity | ± 10 °C |
| Max. Current | 13A |
| Power | 3000 W |
| Inner Chamber Dimension (W x H x D) | 200 x 180 x 300 mm |
| Product Outer Dimension (W x H x D) | 600×780×750 mm |
| Gross Dimension (W x H x D) | 556 x 855 x 708 mm |
| Net Weight | 120 Kg |
| Gross weight | 145 Kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- PID controller
- New mono block body design
- 7 segment display
- Optimum insulation properties
- Direct/ 2 step heating program
- Fe-Cr-Al heating element embedded in brick walls
- K-type thermocouple
- Dual shell housing for low outer surface temperature
Applications
Where it is used
- Our muffle furnace is utilized across diverse industries such as glass, textile, rubber, plastic, biomedical, paint, and metallurgical applications for various heating and processing needs.
- It is used for applications such as: Fusing glass, Creating enamel coatings, Ceramics, Soldering, Brazing, Rubbers & Polymers.It is also used for metallurgical applications, for ash content determination and in research centers and medical laboratories to determine the volatile & non-combustible proportion of the sample.
