Heating, cooling & storage
Lighting Incubator
- Models
- LLI-A10; LLI-A11; LLI-A12; LLI-B10
- Capacity
- 250 L
- Illumination type
- 2 side illumination
- Light source
- Fluorescent lamp
- Lighting illumination
- 0 to 12000 lx
Lighting Incubator LLI-A10 come with amazing features like Ambient temperature with 5 °C to 35 °C, Capacity with 250 L, Continuous working time with ≥ 180 h, External dimension (W × D × H) w…
Added to your inquiry list. It travels with your next quote request.
4 models
Product Description
Lighting Incubator specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LLI-A10 — Lighting Incubator | |
| Capacity | 250 L |
| Illumination type | 2 side illumination |
| Light source | Fluorescent lamp |
| Lighting illumination | 0 to 12000 lx |
| Illumination control | 6 degrees adjustable |
| Temperature range | With illumination: 10 to 50 °C, without illumination: 5 to 50 °C |
| Temperature control | 0.1 °C |
| Temperature accuracy | ± 1 °C |
| Temperature uniformity | ± 1 °C |
| Refrigerant | R134a (CFC-free refrigerant, eco-friendly) |
| Ambient temperature | 5 °C to 35 °C |
| Number of Shelves | 3 (pcs) |
| Continuous working time | ≥ 180 h |
| Power | 640 W |
| Power supply | AC220 V ± 10 %, 50/60 Hz |
| Internal dimension (W × D × H) | 555 × 450 × 1100 mm |
| External dimension (W × D × H) | 680 × 680 × 1760 mm |
| Packaging dimension (W × D × H) | 820 × 800 × 1920 mm |
| Net weight | 120 kg |
| Gross weight | 150 kg |
| LLI-A11 — Lighting Incubator | |
| Capacity | 350 L |
| Illumination type | 2 side illumination |
| Light source | Fluorescent lamp |
| Lighting illumination | 0 to 15000 lx |
| Illumination control | 6 degrees adjustable |
| Temperature range | With illumination: 10 to 50 °C, without illumination: 5 to 50 °C |
| Temperature control | 0.1 °C |
| Temperature accuracy | ± 1 °C |
| Temperature uniformity | ± 2 °C |
| Refrigerant | R134a (CFC-free refrigerant, eco-friendly) |
| Ambient temperature | 5 °C to 35 °C |
| Number of Shelves | 3 (pcs) |
| Continuous working time | ≥ 180 h |
| Power | 1600 W |
| Power supply | AC220 V ± 10 %, 50/60 Hz |
| Internal dimension (W × D × H) | 550 × 550 × 1200 mm |
| External dimension (W × D × H) | 880 × 800 × 1900 mm |
| Packaging dimension (W × D × H) | 940 × 990 × 2080 mm |
| Net weight | 140 kg |
| Gross weight | 160 kg |
| LLI-A12 — Lighting Incubator | |
| Capacity | 450 L |
| Illumination type | 2 side illumination |
| Light source | Fluorescent lamp |
| Lighting illumination | 0 to 20000 lx |
| Illumination control | 6 degrees adjustable |
| Temperature range | With illumination: 10 to 50 °C, without illumination: 5 to 50 °C |
| Temperature control | 0.1 °C |
| Temperature accuracy | ± 1 °C |
| Temperature uniformity | ± 2 °C |
| Refrigerant | R134a (CFC-free refrigerant, eco-friendly) |
| Ambient temperature | 5 °C to 35 °C |
| Number of Shelves | 4 (pcs) |
| Continuous working time | ≥ 180 h |
| Power | 1750 W |
| Power supply | AC220 V ± 10 %, 50/60 Hz |
| Internal dimension (W × D × H) | 700 × 550 × 1200 mm |
| External dimension (W × D × H) | 1030 × 800 × 1900 mm |
| Packaging dimension (W × D × H) | 940 × 1140 × 2080 mm |
| Net weight | 165 kg |
| Gross weight | 185 kg |
| LLI-B10 — Lighting Incubator | |
| Capacity | 200 L |
| Light source | LED |
| Lighting illumination | 0 to 20,000 lx |
| Illumination control | 5-grade adjustable |
| Temperature range | With illumination: 10 to 60 °C, without illumination: 5 to 60 °C |
| Temperature resolution | 0.1 °C |
| Temperature Fluctuation | ± 0.5 °C |
| Temperature deviation | ± 1.0 °C |
| Internal thermal homogeneity | ± 1 °C |
| Internal thermal stability | ± 0.5 °C |
| Ambient temperature | 0 to 40 °C |
| Number of Shelves | 2 pcs |
| Continuous working time | 0 to 99 cycle, 0 to 9999 hours (minutes) |
| Display | LCD |
| Display resolution | 0.1 |
| Heating power | 900 W |
| Cooling power | 300 W |
| Power supply | AC 220 V ± 10 %, 50/60 Hz |
| Internal Dimensions | 476 × 548 × 778 mm |
| External Dimensions | 760 × 750 × 1500 mm |
| Gross weight | 200 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Microprocessor PID temperature control system
- 2 side illumination
- LCD display
- 3 pcs shelves
- Polished stainless steel chamber
- Round angle structure, easy to clean
- R134a refrigerant (CFC-free refrigerant, eco-friendly)
- Over temperature protection
Applications
Where it is used
- Lighting Incubator is widely used in the field of pharmacy, chemical industry, environmental industry, agriculture industry and for scientific research.
