Weighing & measurement
Halogen Moisture Analyzer
- Models
- LHMA-A10; LHMA-A11; LHMA-A12; LHMA-A13; LHMA-A14
- Range
- 0.005 g to 110 g
- Readability
- 0.005 g
- Temperature range
- 40 to 160℃
- Heat source
- Halogen lamp
Halogen Moisture Analyzer LHMA-A10 come with amazing features like Analysis Curve with Real time dynamic curve, Dimension with 336X214X166 mm, DRY% Readability with 0.05%, Gross Weight with…
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Halogen Moisture Analyzer specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LHMA-A10 — Halogen Moisture Analyzer | |
| Range | 0.005 g to 110 g |
| Readability | 0.005 g |
| Temperature range | 40 to 160℃ |
| Heat source | Halogen lamp |
| Pan size | Φ96mm（20pcs） |
| Operating temperature range | 5 to 35°C |
| Temperature sensor | PT-100-2 |
| Temperature setting | 1°C |
| Moisture Range | 95.00%-5.00% |
| Testing Range | 95.00%-5.00% |
| DRY% Readability | 0.05% |
| Number of storage data | 20 |
| Analysis Curve | Real time dynamic curve |
| Testing Height | 30mm |
| Dimension | 336X214X166 mm |
| Net Weight | 3.5 Kg |
| Packaging Dimension | 42*31*28 cm |
| Gross Weight | 5 Kg |
| LHMA-A11 — Halogen Moisture Analyzer | |
| Range | 5 mg to 110 g |
| Readability | 5 mg |
| Temperature range | 40 to 199°C |
| Heat source | Halogen lamp-1 |
| Pan size | 90 mm diameter |
| Operating temperature range | 5 to 35°C |
| Temperature sensor | PT-100 |
| Temperature step | 1°C |
| Temperature setting | 40 to 199°C by 1°C step |
| Time setting | 1 to 99 min by 10s step |
| Auto stop | 0.1 to 9.9 % within 1 min |
| Dry residual range | 0 to 100 % |
| Dry residual readability | 0.001 |
| Moisture range | 0 to 100 % |
| Moisture readability | 0.001 |
| Number of storage data | 15 |
| Number of history data | 15 |
| Display | 5 inch touch panel |
| Interface | RS232 |
| Machine dimension | 490 × 360 × 350 mm |
| Gross weight | 7.5 kg |
| LHMA-A12 — Halogen Moisture Analyzer | |
| Range | 2 mg to 110 g |
| Readability | 2 mg |
| Temperature range | 40 to 199°C |
| Heat source | Halogen lamp-1 |
| Pan size | 90 mm diameter |
| Operating temperature range | 5 to 35°C |
| Temperature sensor | PT-100 |
| Temperature step | 1°C |
| Temperature setting | 40 to 199°C by 1°C step |
| Time setting | 1 to 99 min by 10s step |
| Auto stop | 0.1 to 9.9 % within 1 min |
| Dry residual range | 0 to 100 % |
| Dry residual readability | 0.0004 |
| Moisture range | 0 to 100 % |
| Moisture readability | 0.0004 |
| Number of storage data | 15 |
| Number of history data | 15 |
| Display | 5 inch touch panel |
| Interface | RS232 |
| Machine dimension | 490 × 360 × 350 mm |
| Gross weight | 7.5 kg |
| LHMA-A13 — Halogen Moisture Analyzer | |
| Range | 1 mg to 110 g |
| Readability | 1 mg |
| Temperature range | 40 to 199°C |
| Heat source | Halogen lamp-1 |
| Pan size | 90 mm diameter |
| Operating temperature range | 5 to 35°C |
| Temperature sensor | PT-100 |
| Temperature step | 1°C |
| Temperature setting | 40 to 199°C by 1°C step |
| Time setting | 1 to 99 min by 10s step |
| Auto stop | 0.1 to 9.9 % within 1 min |
| Dry residual range | 0 to 100 % |
| Dry residual readability | 0.0001 |
| Moisture range | 0 to 100 % |
| Moisture readability | 0.0001 |
| Number of storage data | 15 |
| Number of history data | 15 |
| Display | 5 inch touch panel |
| Interface | RS232 |
| Machine dimension | 490 × 360 × 350 mm |
| Gross weight | 7.5 kg |
| LHMA-A14 — Halogen Moisture Analyzer | |
| Range | 1 mg to 110 g |
| Readability | 1 mg |
| Temperature range | 40 to 199°C |
| Heat source | Halogen lamp-2 |
| Pan size | 90 mm diameter |
| Operating temperature range | 5 to 35°C |
| Temperature sensor | PT-100 |
| Temperature step | 1°C |
| Temperature setting | 40 to 199°C by 1°C step |
| Time setting | 1 to 99 min by 10s step |
| Auto stop | 0.1 to 9.9 % within 1 min |
| Dry residual range | 0 to 100 % |
| Dry residual readability | 0.0001 |
| Moisture range | 0 to 100 % |
| Moisture readability | 0.0001 |
| Number of storage data | 20 |
| Number of history data | 20 |
| Display | 5 inch touch panel |
| Interface | RS232 |
| Machine dimension | 490 × 360 × 350 mm |
| Gross weight | 7.5 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Halogen lamp heating
- Ergonomically designed pan handle
- Digital LCD backlight display
- Locks final test values on display screen
- Stainless steel chamber
- Manual setting for temperature and time
- Easy cleaning after testing
- Stores previous test data
Applications
Where it is used
- Used in biology, food, agriculture, pharmacy, textile, dye and research industries for determination of moisture content in the test sample.
