Safety & containment
Ductless Fume Hood
- Models
- LFH-A20; LFH-A21; LFH-A22; LFH-A23; LFH-A24
- Internal Dimensions (W×D×H)
- 920 × 840 × 940 mm
- External Dimensions (W×D×H)
- 1000 × 880 × 2140 mm
- Work Surface Height
- 820 mm
- Maximum Opening
- 880 mm
Labtron is a trusted supplier of Ductless Fume Hoods. The LFH-A20 ensures 220–1200 m³/h airflow, 50 dB noise level, and arc-shaped steel worktop for safe lab chemical extraction.
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Ductless Fume Hood specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LFH-A20 — Ductless Fume Hood | |
| Internal Dimensions (W×D×H) | 920 × 840 × 940 mm |
| External Dimensions (W×D×H) | 1000 × 880 × 2140 mm |
| Work Surface Height | 820 mm |
| Maximum Opening | 880 mm |
| Air Treatment Capacity | 220 to 1200 m³/h |
| Rated Power | 2000 W |
| Fan Power | 138 W ± 15% |
| Noise Level | 50 dB |
| LED Power | LED6W to LED10W |
| Filtration Technology | Modular carbon and HEPA system |
| Compliance Standards | JG/T 385-2012, NFX 15 211, ANSI Z9.5-2012 |
| Main Body Material | 1.0 mm cold-rolled steel with epoxy coating |
| Worktop Material | 12.7 mm solid physiochemical board |
| Power Supply | 220 V |
| Weight | 128 kg |
| LFH-A21 — Ductless Fume Hood | |
| Internal Dimension (W × D × H) | 1110 × 690 × 740 mm |
| External Dimension (W × D × H) | 1200 × 880 × 2140 mm |
| Work Surface Height | 900 mm |
| Maximum Opening | 650 mm |
| Air Velocity | 0.25 to 0.35 m/s |
| Airflow Volume | 105 m 3 /h |
| Noise | Up to 55 dB (A) |
| Fluorescent Lamp | 16 W × 2 |
| UV Lamp | 253.7 nm emission for efficient decontamination |
| Blower | Built-in centrifugal blower, speed adjustable |
| Front Window | Acrylic; Manual; Reversal design |
| Exterior Material | Cold-rolled steel with anti-bacteria powder coating |
| Side Window Material | Acrylic window |
| Work Table Material | Chemical resistant phenolic resin |
| Chemical Filter | 2 pieces |
| Power | 400 W |
| Power Supply | AC 220 V ± 10%, 50/60 Hz; 110 V ± 10%, 60 Hz |
| Main Body Packaging Dimension | 1350 × 1000 × 1510 mm |
| Base Cabinet Packaging Dimension | 1350 × 1000 × 1080 mm |
| Main Body Gross Weight | 200 kg |
| Base Cabinet Gross Weight | 130 kg |
| LFH-A22 — Ductless Fume Hood | |
| Internal dimension (W × D × H) | 1410 × 690 × 740 mm |
| External dimension (W × D × H) | 1500 × 940 × 2140 mm |
| Work surface height | 900 mm |
| Maximum opening | 650 mm |
| Air velocity | 0.25 to 0.35 m/s |
| Airflow volume | 325 m 3 /h |
| Noise | ≤ 55 dB (A) |
| Fluorescent lamp | 16 W × 3 |
| UV lamp | Emission of 253.7 nanometers for most efficient decontamination |
| Blower | Built-in centrifugal blower, speed adjustable |
| Front window | Acrylic window; Manual; reversal design; |
| Side window | Acrylic Window |
| Work table | Chemical resistant phenolic resin |
| LFH-A23 — Ductless Fume Hood | |
| Internal dimension (W × D × H) | 1710 × 690 × 740 mm |
| External dimension (W × D × H) | 1800 × 940 × 2140 mm |
| Work surface height | 900 mm |
| Maximum opening | 650 mm |
| Air velocity | 0.25 to 0.35 m/s |
| Airflow volume | 415 m 3 /h |
| Noise | ≤ 55 dB (A) |
| Fluorescent lamp | 16 W × 3 |
| UV lamp | Emission of 253.7 nanometers for most efficient decontamination |
| Blower | Built-in centrifugal blower, speed adjustable |
| Front window | Acrylic window; Manual; reversal design; |
| Side window | Acrylic Window |
| Work table | Chemical resistant phenolic resin |
| LFH-A24 — Ductless Fume Hood | |
| Air Capacity | 690 m³/h |
| Face Velocity | 0.4 to 0.6 m/s |
| Noise | 40 to 52 dBA |
| Operation Hole | Trapezoid |
| Rated Currents | 2A |
| Power Consumption | 110W |
| Power Supply | 110V to 240V, 50 - 60 Hz |
| Internal Dimension | 1581 × 574 × 934 mm |
| External Dimension (L W H) | 1600 × 620 × 1245 mm |
| Gross Weight | 250 Kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Touch-sensitive controls
- Energy-efficient LED
- Foldable plexiglass viewing window
- UV safety lock mechanism
- Three-sided glass construction
- Chemical-resistant epoxy coating
- Electronic system for overload and shock protection
- Internal & external air quality probes
Applications
Where it is used
- Our Ductless Fume Hood LFH-A20 is ideal for laboratories needing ductless chemical vapor extraction. It supports clean, localized air management in research, industrial, and academic environments.
- Our Ductless Fume Hood LFH-A21 is used in biotechnology and other branches of life science industry, in pharmaceutical industry to perform experiments or tasks under sterilized work environment.
- Ductless fume hoods are used in laboratories, classrooms, and research facilities to perform experiments or tasks in the sterilized work environment.
