Benchtop Touch Screen Dissolved Oxygen Meter
- Models
- LTSDO-A10
- DO Measuring Range
- 0 to 20.00 mg/L (ppm), 0 to 200.0%
- DO Resolution
- 0.1/0.01 mg/L(ppm), 1/0.1%
- DO Accuracy
- Electrode: ± 0.10 mg/L, Meter: ± 0.40 mg/L
- DO Response Time
- Up to 30s (25℃, 90% response)
Our Touchscreen Dissolved Oxygen Meter offers a measuring range of 0 to 20.00 mg/L ppm. It provides various automatic functions, including auto salinity, auto pressure compensation, and ATC.
Added to your inquiry list. It travels with your next quote request.
1 models
Product Description
Benchtop Touch Screen Dissolved Oxygen Meter specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LTSDO-A10 — Touchscreen Dissolved Oxygen Meter | |
| DO Measuring Range | 0 to 20.00 mg/L (ppm), 0 to 200.0% |
| DO Resolution | 0.1/0.01 mg/L(ppm), 1/0.1% |
| DO Accuracy | Electrode: ± 0.10 mg/L, Meter: ± 0.40 mg/L |
| DO Response Time | Up to 30s (25℃, 90% response) |
| DO Residual Current | Up to 0.1 mg/L |
| DO Temperature Compensation | 0 to 45℃, auto |
| DO Salinity Compensation | 0 to 45 ppt, auto |
| DO Pressure Compensation | 80 to 105 kPa, auto |
| DO Auto Calibration | Air saturated by water, water saturated by air |
| DO Electrode Type | Polarographic |
| Temperature Measuring Range | 0 to 100℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Accuracy | 5 to 60℃: ± 0.4℃ Others: ± 0.8℃ |
| Display | 7-inch colored capacitive touch screen |
| Data Storage | 1000 sets |
| Power | 12V/1A |
| Output | USB |
| Ambient Temperature | 15 to 30 ℃ |
| Ambient Humidity | Up to 85% |
| IP Grade | IP54 |
| Dimensions | 215 × 170 × 37 mm |
| Packaging Dimension | 470 x 430 x 72 mm |
| Net Weight | 600 g |
| Gross Weight | 3 Kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Data storage
- Clock display
- USB output
- Self-diagnosis information
- Light-weight design
Applications
Where it is used
- Labtron’s Benchtop Dissolved Oxygen Meter LTSDO-A10 is used to determine the amount of dissolved oxygen in samples. It is widely used for water quality monitoring, laboratory and research use, agricultural, aquaculture, and environmental applications.
