Benchtop pH Meter
- Models
- LBPM-A11; LBPM-A20; LBPM-B10; LBPM-B11; LBPM-C11
- pH measurement range
- 0.00 to 14.00 pH
- pH accuracy
- ± 0.01 pH
- pH resolution
- 0.01 pH
- Calibration points
- 2 points
We are manufacturers of Benchtop pH Meter LBPM-A11 featuring automatic 2 point calibration for identifying pH buffer and a smart backlit LCD display for ease of monitoring.
Added to your inquiry list. It travels with your next quote request.
5 models
Product Description
Benchtop pH Meter specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LBPM-A11 — Benchtop pH Meter | |
| pH measurement range | 0.00 to 14.00 pH |
| pH accuracy | ± 0.01 pH |
| pH resolution | 0.01 pH |
| Calibration points | 2 points |
| Calibration solutions | USA (pH 4.0/7.00/10.01) |
| Temperature compensation | 0 to 100°C |
| Compensation mode | Manual or automatic |
| mV range | -1999 to 1999 mV |
| mV accuracy | ±1mV |
| mV resolution | 1 mV |
| Temperature range | 0 to 100°C, 32 to 212°F |
| Temperature accuracy | ±1°C |
| Temperature resolution | 1°C |
| Connector | BNC |
| Display | LCD |
| Dimension (L*W*H) | 210×205×65 mm |
| Power | DC9V, Ac adapter, AC220V /50Hz |
| Net Weight | 1.5 kg |
| Gross Weight | 3 kg |
| LBPM-A20 — Benchtop pH Meter | |
| pH measurement range | -1.00 to 15.00 pH |
| pH accuracy | ± 0.01 pH |
| pH resolution | 0.01 pH |
| Calibration points | 1-3 points |
| Buffer Sets | USA (pH 4.0/7.00/10.01), NIST (pH 4.01/6.86/9.18) |
| Temperature compensation | 0 to 100°C, 32 to 212°F |
| Compensation mode | Manual or automatic |
| mV range | -1000 to 1000 mV |
| mV accuracy | ±1mV |
| mV resolution | 1 mV |
| Temperature range | 0 to 105°C, 32 to 221°F |
| Temperature accuracy | ±1°C |
| Temperature resolution | 0.1°C |
| Hold function | Manual or automatic endpoint detection |
| Power off | Manual or automatic (180 minutes after last key is pressed) |
| Reset function | Yes |
| Connector | BNC |
| Display | LCD |
| Dimension (L*W*H) | 210×205×75 mm |
| Weight | 1.5 kg |
| Power | DC9V, AC adapter, AC220V/50Hz |
| LBPM-B10 — Benchtop pH Meter | |
| pH measurement range | -2.000 to 20.000 pH |
| pH accuracy | ± 0.002 pH |
| Calibration points | 1-5 points |
| Calibration solutions | USA, NIST, DIN or user defined |
| ORP measurement range | -1999.9 to 1999.9 mV |
| ORP accuracy | ±0.2 mV |
| ORP calibration points | 1 point |
| ORP calibration range | ±200 mV |
| ORP calibration solutions | mV & relative mV |
| Temperature compensation | 0 to 100°C, 32 to 212°F |
| Compensation mode | Manual or automatic |
| Stability conditions | Low or high |
| Calibration due | 0 to 31 days |
| memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC |
| Display | LCD |
| Dimension (L*W*H) | 210×188×60 mm |
| Weight | 1 kg |
| Power | DC5V using AC adapter, AC220V /50 Hz |
| Gross Weight | 1.8 Kg |
| LBPM-B11 — Benchtop pH Meter | |
| Temperature compensation | 0 to 100°C, 32°F to 212°FManual or Automatic |
| Hold function | Manual or automatic endpoint detection |
| Stability criteria | Standard or High-accuracy |
| Interval readings | 10, 30, 60 seconds, 10, 30 minutes or Off |
| Calibration due alarm | 1 to 31 days |
| Memory | Stores up to 1000 data sets |
| Output | USB communication interface |
| Display | 7 inch TFT LCD |
| Accuracy | ± 0.002 pH |
| Resolution | 0.001, 0.01 pH |
| Calibration points | 1 to 5 points |
| LBPM-C11 — Benchtop pH Meter | |
| pH Measuring Range | -2.0 to 19.99 pH |
| pH Accuracy | Meter: ±0.01 pH; Complete Kit: ±0.02 pH |
| pH Resolution | 0.1 / 0.01 pH |
| Calibration Points | 1, 2, 3 points |
| ORP Measuring Range | ±1999.9 mV |
| ORP Resolution | 0.1 mV |
| ORP Accuracy | ±0.03% FS |
| Temperature Range | 0 °C to 100 °C |
| Temperature Accuracy | ±0.4 °C (5 °C to 60 °C) |
| Temperature Resolution | 0.1 °C |
| Temperature Compensation | Auto or Manual |
| Buffer Standards | Europe, USA, NIST |
| Input Current | ≤2×10⁻¹² A |
| Input Impedance | ≥1×10¹² Ω |
| Stability | ±0.02 pH / 3 h |
| Data Storage | 1000 sets |
| Display | 6.5 inch LCD |
| Output | USB |
| Ambient Temperature | 5 °C to 35 °C |
| Ambient Humidity | Upto 85% |
| IP Rating | IP54 |
| Power Supply | 12V/1A |
| Dimensions | 215 × 170 × 37 mm |
| Weight | 0.6 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Equipped with white backlit LCD display
- pH measurement range 0.0 to 14.00 pH
- 2 points calibration to automatically identify pH buffer
- Automatic electrode slope display, helps the operator when to replace the sensor
- Automatic temperature compensation for accurate measured value over the entire range
- Universal BNC connector
- Built-in solution holder
- pH measurement range: -1.00 to 15.00 pH
Applications
Where it is used
- The benchtop pH meter can be used for daily measurement of pH & temperature at schools, colleges & research laboratories & water testing plants.
- Benchtop pH meter is used for research education purpose, quality testing in water and waste water management plants, food and beverage industry & other liquids & solvents.
- The benchtop pH meter can be used for daily measurement of pH, ORP & temperature at schools, colleges & research laboratories & water testing plants.
- Used for daily measurement of pH, ORP and temperature at schools, colleges and research laboratories and water testing plants
- Our Benchtop pH Meter LBPM-C11 is widely used in environmental testing and industrial labs. It is suitable for quality analysis in chemical production, wastewater treatment, and agriculture labs.
