Automatic Density Meter
- Models
- LBDM-A10; LBDM-A11; LBDM-A12; LBDM-A13
- Measuring Range
- 0 g/cm³ to 3 g/cm³
- Resolution
- ±0.00001 g/ cm³
- Repeatability
- ±0.00005 g/ cm³
- Accuracy
- ±0.00008 g/ cm³
Labtron
Added to your inquiry list. It travels with your next quote request.
4 models
Product Description
Automatic Density Meter specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LBDM-A10 — Automatic Density Meter | |
| Measuring Range | 0 g/cm³ to 3 g/cm³ |
| Resolution | ±0.00001 g/ cm³ |
| Repeatability | ±0.00005 g/ cm³ |
| Accuracy | ±0.00008 g/ cm³ |
| Test Mode | Density, alcohol concentration, and custom formula |
| Injection Method | Automatic (compatible with manual) |
| Temperature Control Method | Peltier |
| Temperature Control Range | 5℃ to 65℃ |
| Temperature Control Stability | ±0.02℃ |
| Display | 10.4-inch FTF color touchscreen |
| Data Storage | 64G |
| Output Method | USB, RS232, U disk |
| Standards | ASTM D1250, D1475, D2501, D4052, D4806, D5002, D5931, D6448 |
| Export In Multiple File Formats | PDF & Excel |
| Power Supply | 110V -230V 50Hz / 60Hz |
| Dimension | 425×410×250 mm |
| Weight | 8.5 Kg |
| LBDM-A11 — Automatic Density Meter | |
| Measuring Range | 0 g/cm³ to 3 g/cm³ |
| Resolution | ±0.0001 g/ cm³ |
| Repeatability | ±0.0001 g/ cm³ |
| Accuracy | ±0.0003 g/cm³ |
| Test Mode | Density, alcohol concentration, and custom formula |
| Injection Method | Automatic (compatible with manual) |
| Temperature Control Method | Peltier |
| Temperature Control Range | 5℃ to 45℃ |
| Temperature Control Stability | ±0.02℃ |
| Display | 10.4-inch FTF color touchscreen |
| Data Storage | 32G |
| Output Method | USB, RS232, U disk |
| Standards | ASTM D1250, D1475, D2501, D4052, D4806, D5002, D5931, D6448 |
| Export In Multiple File Formats | PDF & Excel |
| Power Supply | 110V -230V 50Hz / 60Hz |
| Dimension | 405×390×220 mm |
| Packaging Dimensions | 435×420×280 mm |
| Weight | 8.5 Kg |
| Gross Weight | 12.05kg |
| LBDM-A12 — Automatic Density Meter | |
| Measuring Range | 0.001 g/cm³ to 3g /cm³ |
| Density Resolution | ± 0.001 g /cm³ |
| Repeatability | ± 0.0008 g /cm³ |
| Accuracy | ± 0.0008 g /cm³ |
| Test Range | 0 to 3g /cm³ |
| Injection Method | Fully Automatic |
| Temperature Control Mode | Peltier control temperature |
| Temperature Control Range | 5℃ to 45℃ |
| Temperature Control Stability | ± 0.02°C |
| Video Function | Yes |
| Display Screen | 10.4 FTF color touch screen |
| Data Storage | 32 GB |
| Output Method | Standard: RS232. RJ 45, SD card, U disk, USB can be customized |
| Power Supply | 110 to 230 V 50 Hz / 60 Hz |
| Dimensions (L× W× H) | 480mm × 320mm × 200mm |
| Weight | 8 kg |
| LBDM-A13 — Automatic Density Meter | |
| Measuring Range | 0.001 to 3g /cm3 |
| Density Resolution | ± 0.001 g /cm3 |
| Repeatability | ± 0.0005 g /cm3 |
| Accuracy | ± 0.0008 g /cm3 |
| Test Range | 0 to 3g /cm3 |
| Injection Method | Fully Automatic |
| Temperature Control Mode | Peltier control temperature |
| Temperature Control Range | 5℃ to 45℃ |
| Temperature Control Stability | ± 0.02°C |
| Video Function | Yes |
| Display Screen | 10.4 FTF color touch screen |
| Data Storage | 64 GB |
| Output Method | Standard: RS232. RJ 45, SD card, U disk, USB can be customized |
| Power Supply | 110 to 230 V 50 Hz / 60 Hz |
| Dimensions (L× W× H) | 480mm × 320mm × 200mm |
| Weight | 8 kg |
Specification published by Labtron. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- Compact and durable design
- Ultra-high measurement resolution
- Expanded temperature control range
- ASTM-compliant measurement standards
- Advanced electronic signature and audit trail
- Secure multi-level user access
- Supports direct Wi-Fi printing
- Multi-format report exports
Applications
Where it is used
- Our Automatic Density Meter LBDM-A10 is perfect for chemical formulation testing, alcohol measurement in brewing industries, and API quality control in pharmaceutical research.
- Our Automatic Density Meter LBDM-A11 is used in pharmaceuticals, food, beverages, and petrochemicals for API testing, sugar analysis, alcohol measurement, and fuel density checks. It also supports chemical processing and industrial manufacturing.
- Automatic Density Meter LBDM-A12 is a self-operating device that continuously measures the density of liquids. It plays a key role in petrochemical, oil refining, pharmaceuticals, metallurgy, battery manufacturing and water treatment in quality control of different products.
- Automatic Density Meter LBDM-A13 determines liquid density with high accuracy and minimal user interaction. It plays a key role in pharmaceutical, chemical industry, petroleum and automotive industries for purity analysis and quality control.
