Temperature and Humidity Test Chamber
- Models
- LZ-THC-A100; LZ-THC-A101; LZ-THC-A102; LZ-THC-A103; LZ-THC-A104; LZ-THC-B100; LZ-THC-C100; LZ-THC-D100
- Capacity
- 80 L
- Temperature Range
- 5 to 80°C
- Display Resolution
- 0.1℃
- Temperature Stability
- High ±0.5℃ Low ±1℃
Temperature and Humidity Test Chamber LZ-THC-A100 is designed with 80 L chamber volume. Designed to function with 40 to 85 % RH humidity range and 5 to 80°C temperature range parameters.
Added to your inquiry list. It travels with your next quote request.
8 models
Product Description
Temperature and Humidity Test Chamber specification for every model we supply. Figures are the manufacturer’s published values.
| Specification | Value |
|---|---|
| LZ-THC-A100 — Temperature and Humidity Test Chamber | |
| Capacity | 80 L |
| Temperature Range | 5 to 80°C |
| Display Resolution | 0.1℃ |
| Temperature Stability | High ±0.5℃ Low ±1℃ |
| Temperature Uniformity | ±2℃ |
| Humidity Range | 40 to 85 % |
| Humidity Accuracy | ±3 % RH |
| Ambient Temperature | +5 to 35℃ |
| Shelves | 2 pcs |
| Internal Dimension | 400 × 400 × 500 mm |
| External Dimension | 550 × 790 × 1080 mm |
| Power Consumption | 2000 W |
| Power supply | 220 V, 50 Hz |
| Net weight | 122 kg |
| Gross weight | 165 kg |
| LZ-THC-A101 — Temperature and Humidity Test Chamber | |
| Capacity | 150 L |
| Temperature Range | 5 to 80°C |
| Display Resolution | 0.1℃ |
| Temperature Stability | High ±0.5℃ Low ±1℃ |
| Temperature Uniformity | ±2℃ |
| Humidity Range | 40 to 85 % |
| Humidity Accuracy | ±3 % RH |
| Ambient Temperature | +5 to 35℃ |
| Shelves | 3 pcs |
| Internal Dimension | 550 × 405 × 670 mm |
| External Dimension | 690 × 800 × 1430 mm |
| Power Consumption | 2100 W |
| Power supply | 220 V, 50 Hz |
| Net weight | 186 kg |
| Gross weight | 216 kg |
| LZ-THC-A102 — Temperature and Humidity Test Chamber | |
| Capacity | 250 L |
| Temperature Range | 5 to 80°C |
| Display Resolution | 0.1℃ |
| Temperature Stability | High ±0.5℃ Low ±1℃ |
| Temperature Uniformity | ±2℃ |
| Humidity Range | 40 to 85 % |
| Humidity Accuracy | ±3 % RH |
| Ambient Temperature | +5 to 35℃ |
| Shelves | 3 pcs |
| Internal Dimension | 600 × 500 × 830 mm |
| External Dimension | 740 × 900 × 1580 mm |
| Power Consumption | 2300 W |
| Power supply | 220 V, 50 Hz |
| Net weight | 230 kg |
| Gross weight | 340 kg |
| LZ-THC-A103 — Temperature and Humidity Test Chamber | |
| Capacity | 500 L |
| Temperature Range | 5 to 80°C |
| Display Resolution | 0.1℃ |
| Temperature Stability | High ±0.5℃ Low ±1℃ |
| Temperature Uniformity | ±2℃ |
| Humidity Range | 40 to 85 % |
| Humidity Accuracy | ±3 % RH |
| Ambient Temperature | +5 to 35℃ |
| Shelves | 4 pcs |
| Internal Dimension | 670 × 720 × 1020 mm |
| External Dimension | 850 × 1100 × 1930 mm |
| Power Consumption | 3850 W |
| Power supply | 220 V, 50 Hz |
| Net weight | 270 kg |
| Gross weight | 430 kg |
| LZ-THC-A104 — Temperature And Humidity Test Chamber | |
| Capacity | 800 L |
| Temperature Range | 5 to 80°C |
| Display Resolution | 0.1℃ |
| Temperature Stability | High ±0.5℃ Low ±1℃ |
| Temperature Uniformity | ±2℃ |
| Humidity Range | 40 to 85 % |
| Humidity Accuracy | ±3 % RH |
| Ambient Temperature | +5 to 35℃ |
| Shelves | 4 pcs |
| Internal Dimension | 800 × 590 × 1650 mm |
| External Dimension | 1360 × 890 × 2000 mm |
| Power Consumption | 8050 W |
| Power supply | 220 V, 50 Hz |
| Net weight | 420 kg |
| Gross weight | 470 kg |
| LZ-THC-B100 — Temperature And Humidity Test Chamber | |
| Chamber Volume | 80 L |
| Temperature control range | 0 ~ 100°C |
| Temperature Fluctuation | ±0.5°C |
| Humidity Range | 30 ~ 98% RH |
| Humidity Stability | ±2% RH |
| Humidity Accuracy | 0.1% RH |
| Controller | LED digital display temperature PID humidity controller |
| Test Area | SUS 304 Stainless steel |
| LZ-THC-C100 — Temperature And Humidity Test Chamber | |
| Chamber Volume | 50 L |
| Temperature Control Range | 0 ~ +150°C |
| Temperature Fluctuation | ±0.5°C |
| Humidity Range | 20 ~ 98% RH |
| Humidity Stability | ±2.0% RH |
| Heating Rate | 3°C/ min |
| Cooling Rate | 1°C/min |
| Working Condition | 5℃～+35℃ ≤85%RH |
| Refrigeration | French TECUMSEH compressor |
| Refigerant | R449A |
| LZ-THC-D100 — Temperature And Humidity Test Chamber | |
| Chamber Volume | 60 L |
| Temperature Range | -25 to +150°C |
| Temperature Fluctuation | ±0.3°C |
| Humidity Range | 20-98% RH |
| Humidity Fluctuation | ±2% RH |
| Accuracy Settings | Temperature: 0.1°C Humidity: 0.1%RH Time: 1min |
| Program Value | 100 |
| Display | LCD |
| Controller | PID |
| Sensor | PT100 |
| Operation Mode | Constant & Programmable |
| Data Storage | Test data recorded in controller and downloaded via USB |
| Heating System | Heat Control Part: SSR Solid state relay Heater: Stainless steel |
| Humidifying System | Humidifier: Built-in boiler steam humidifier Mode: Steam-humidifying |
| Dehumidifying System | Evaporator coil dew-point temperature laminar flow contact |
| Water Tank | Plastic water tank in drawer at bottom |
| Material | External: Electrostatically painted stainless steel Internal: SUS304 |
| Insulation | Glass wool |
| Door | Single |
| Shelf | 2 adjustable stainless steel |
| Port Hole | Ф50 mm port hole on left side |
| Compressor | SECOP |
| Refrigerant | Environmental friendly |
| Cooling | Air |
| Air circulation | Stainless steel long axial fan blower |
| Alarms | Audible and Visual |
Specification published by Labozon. Confirm the exact configuration on the written quotation before ordering.
Key features
What the range offers
- PID microprocessor controller system controls main unit, temperature system and display
- Polished stainless-steel chamber, semicircular arcs at corners for easy cleaning
- Chamber offers adjustable space between shelves
- Adopted with imported compressor
- Equipped with independent temperature-limiting alarm system ensures experiments run safely
- Offers 25 mm instruction connection hole on the left side of the chamber for easy testing operation and temperature measurement
- 4 movable castors for ease moving, and with brakes function
- Test data is stored in controller and can be downloaded via USB
Applications
Where it is used
- Temperature and Humidity Test Chamber is used in food industry, advanced research and pharmaceutical industries, chemical industries, industries that includes testing products relating to aerospace, electronics, automobile and environmental stress screening etc.
- Ideal for accelerated aging studies and reliability testing of materials, components and finished products under controlled temperature and humidity conditions.
