Labozon Laminar Flow Cabinet, model LZ-HLF-A100

Labozon Safety & containment

Laminar Flow Cabinet

Models
LZ-HLF-A100; LZ-HLF-A110; LZ-HLF-A120; LZ-VLF-A100D; LZ-VLF-A110D
Type
Single-Single-Horizontal
Cleanliness
Grade 100
Velocity
0.25 to 0.45 m/s
Material
304 Stainless steel

Horizontal and vertical clean-air workstations for product protection.

Labozon 5 models

Product Description

Laminar Flow Cabinet specification for every model we supply. Figures are the manufacturer’s published values.

Laminar Flow Cabinet specification, by model, as published by Labozon
SpecificationValue
LZ-HLF-A100 — Horizontal Laminar Flow Cabinet
TypeSingle-Single-Horizontal
CleanlinessGrade 100
Velocity0.25 to 0.45 m/s
Material304 Stainless steel
No. of colony≤0.5per utensil.hour(90mm utensil)
Noise≤62dB
Illumination≥300LX
LightLED
HEPA filter No. and Size695x600x38 mm x1
Power Consumption300 W
CertificationISO 9001
Working Area700x400x600 mm
Overall Dimension850x580x1600 mm
Weight160 kg
Electrical RequirementAC220 V/50Hz
LZ-HLF-A110 — Horizontal Laminar Flow Cabinet
TypeSingle-Single-Horizontal
CleanlinessGrade 100
Velocity0.25 to 0.45 m/s
Material304 Stainless steel
No. of colony≤0.5per utensil.hour(90mm utensil)
Noise≤62dB
Illumination≥300LX
LightLED
HEPA filter No. and Size20W*1/20W*1
Power Consumption320 W
CertificationISO 9001
Working Area850×580×1600 mm
Overall Dimension850×580×1600 mm
Weight160 kg
Electrical RequirementAC220 V/50Hz
LZ-HLF-A120 — Horizontal Laminar Flow Cabinet
TypeSingle-Single-Horizontal
CleanlinessGrade 100
Velocity0.25 to 0.45 m/s
Material304 Stainless steel
No. of colony≤0.5per utensil.hour(90mm utensil)
Noise≤62dB
Illumination≥300LX
LightLED
HEPA filter No. and Size20W*1/20W*1
Power Consumption320 W
CertificationISO 9001
Working Area870x550x620 mm
Overall Dimension1050x730x1600 mm
Weight160 kg
Electrical RequirementAC220 V/50Hz
LZ-VLF-A100D — Vertical Laminar Flow Cabinet (Double Sided)
TypeSingle-Double-Vertical(Medical
CleanlinessGrade 100
Velocity0.25-0.45m/s
Material304 Stainless steel
No. of colony≤0.5per utensil.hour(90mm utensil)
Noise≤62dB
Illumination≥300LX
LightLED
HEPA filter No. and Size865x555x38x1
Power Consumption400 W
CertificationISO 9001
Working Area870x600x520 mm
Overall Dimension1050x680x1600 mm
Weight75 kg
Electrical RequirementAC 220 V/50Hz
LZ-VLF-A110D — Vertical Laminar Flow Cabinet (Double Sided)
TypeDouble-Double-Vertical(Medical
CleanlinessGrade 100
Velocity0.25-0.45m/s
Material304 Stainless steel
No. of colony≤0.5per utensil.hour(90mm utensil)
Noise≤62dB
Illumination≥300LX
LightLED
HEPA filter No. and Size1355x555x38x1
Power Consumption800 W
CertificationISO 9001
Working Area1360x600x520 mm
Overall Dimension1540x680x1600 mm
Weight150 kg
Electrical RequirementAC 220 V/50Hz

Specification published by Labozon. Confirm the exact configuration on the written quotation before ordering.

Key features

What the range offers

  • Instrument designed with powerful, low-energy fan and filter modules deliver a back-to-front laminar flow with aids of HEPA filter air across the work surface
  • Furnished with ISO-9001 and grade 100 work zone
  • Suitable for important operations in the medical, biotech, pharmaceuticals, electronics and semiconductor industries
  • Built-in illuminator provides diffused lighting without interfering with laminar flow with value range up to: ≥ 300 Lx
  • This advanced flow cabinet operate with a LED panel
  • Novel structures that maintains outstanding performance with low noise at ≤62 dB(A)
  • Inner surfaces, including the side panels and work surface, are made of 304-stainless steel
  • Come with Single-Single and Double Horizontal operation mode

Applications

Where it is used

  • Used in medicine, pharmacy, and biological, chemical experiment, operating room, foodstuff, drinks, and cosmetic, stock rising and aviation works.
